Crankcase Diagram Yamaha SRT1100 SX230HO
- Model code
- SRT1100-E SX230HO
- Engine Capacity
- 2x1100
- Year
- 2006
- Sales region
- Europe (010)
- Colour
- White Coat 5 (WC5; GA5E)
- Color Variant
- A
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
6B6-15100-00-00 Crankcase Assy |
6B6-15100-00-00 |
from US $1,748.86 |
||
|
2
|
2
995-30100-14-00
Pin, Dowel
|
995-30100-14-00 |
— | ||
| replacements | |||||
|
2
|
2
99530-10114-00 Pin, Dowel |
99530-10114-00 |
from US $1.94 |
||
|
2
|
2
995-10101-14-00
Pin, Dowel
|
995-10101-14-00 |
— | ||
|
3
|
3
6B6-W009B-00-8P Cylinder Block Assy |
6B6-W009B-00-8P |
from US $5,665.25 |
||
| replacement | |||||
|
3
|
3
6B6-W009B-01-8P Cylinder Block Assy |
6B6-W009B-01-8P |
from US $5,664.16 |
||
|
4
|
4
90116-10619-00 Bolt, Stud |
90116-10619-00 |
from US $7.01 |
||
|
5
|
5
90105-093A5-00 Bolt, Flange |
90105-093A5-00 |
from US $1.82 |
||
|
6
|
6
902-01096-J9-00 Washer, Plate |
902-01096-J9-00 |
from US $1.65 |
||
|
7
|
7
995-30100-14-00
Pin, Dowel
|
995-30100-14-00 |
— | ||
| replacements | |||||
|
7
|
7
99530-10114-00 Pin, Dowel |
99530-10114-00 |
from US $1.94 |
||
|
7
|
7
995-10101-14-00
Pin, Dowel
|
995-10101-14-00 |
— | ||
|
8
|
8
90109-06051-00 Bolt |
90109-06051-00 |
from US $5.08 |
||
|
9
|
9
90105-06033-00 Bolt, Flange |
90105-06033-00 |
from US $2.54 |
||
| replacement | |||||
|
9
|
9
95814-06070-00 Bolt, Flange |
95814-06070-00 |
from US $1.50 |
||
|
10
|
10
90105-06M17-00 Bolt, Washer Based |
90105-06M17-00 |
US $2.24 |
||
|
11
|
11
67F-11325-01-00 Anode |
67F-11325-01-00 |
from US $11.67 |
||
|
12
|
12
67F-11328-00-00
Grommet, Anode
|
67F-11328-00-00 |
— | ||
| replacement | |||||
|
12
|
12
67F-11328-01-00 GROMMET ANODE |
67F-11328-01-00 |
from US $2.09 |
||
|
13
|
13
69J-11327-01-94 Cover, Anode |
69J-11327-01-94 |
US $13.37 |
||
| replacement | |||||
|
13
|
13
69J-11327-01-00 Cover, Anode |
69J-11327-01-00 |
US $13.37 |
||
|
14
|
14
975-95085-20-00
Bolt
|
975-95085-20-00 |
— | ||
| replacement | |||||
|
14
|
14
97080-08020-00 Bolt(6Td) |
97080-08020-00 |
from US $4.04 |
||
|
15
|
15
97595-08540-00 Bolt, With Washer |
97595-08540-00 |
from US $1.50 |
||
|
16
|
16
6B6-1310A-00-94 Pan, Oil |
6B6-1310A-00-94 |
from US $72.89 |
||
| replacements | |||||
|
16
|
16
6B6-1310A-01-94 Pan, Oil |
6B6-1310A-01-94 |
from US $72.89 |
||
|
16
|
16
6B6-1310A-01-00 PAN OIL |
6B6-1310A-01-00 |
from US $55.94 |
||
|
17
|
17
6B6-13557-00-00 Gasket |
6B6-13557-00-00 |
from US $16.76 |
||
| replacement | |||||
|
17
|
17
6B6-13557-01-00 Gasket |
6B6-13557-01-00 |
from US $16.76 |
||
|
18
|
18
975-15065-20-00
Bolt, With Washer
|
975-15065-20-00 |
— | ||
|
19
|
19
936-0614M-15-00
Pin, Dowel
|
936-0614M-15-00 |
— | ||
|
20
|
20
60E-13161-00-00 Pipe, Delivery 1 |
60E-13161-00-00 |
from US $18.40 |
||
|
21
|
21
932-10066-67-00 O-Ring |
932-10066-67-00 |
from US $1.80 |
||
|
22
|
22
950-27060-10-00 Bolt, Flange(4My) |
950-27060-10-00 |
from US $0.90 |
||
|
23
|
23
99530-08012-00 Pin, Dowel |
99530-08012-00 |
from US $0.90 |
||
|
24
|
24
93210-08001-00 O-Ring |
93210-08001-00 |
from US $1.49 |
||
|
25
|
25
5GH-13440-00-00
Element Assy, Oil Cleaner
|
5GH-13440-00-00 |
— | ||
| replacement | |||||
|
25
|
25
5GH-13440-71-00 ELEMENT ASSY, OIL CLEANER |
5GH-13440-71-00 |
from US $18.15 |
||
|
26
|
26
90401-20145-00 Bolt, Union |
90401-20145-00 |
from US $14.36 |
||
| replacement | |||||
|
26
|
26
90401-20007-00 Bolt, Union |
90401-20007-00 |
from US $14.36 |
||
|
27
|
27
68N-44517-00-94 Mount Rubber |
68N-44517-00-94 |
from US $101.67 |
||
| replacement | |||||
|
27
|
27
68N-44517-00-00 Mount Rubber |
68N-44517-00-00 |
from US $101.67 |
||
|
28
|
28
6B6-44532-00-94 Stopper, Upper Mount |
6B6-44532-00-94 |
from US $42.07 |
||
|
29
|
29
90119-08835-00 Bolt, With WasherYMUS |
90119-08835-00 |
from US $7.72 |
||
| replacement | |||||
|
29
|
29
901-19088-58-00 Bolt, With WasherYMUS |
901-19088-58-00 |
from US $7.72 |
||
|
30
|
30
90201-099U3-00 Washer, PlateYMUS |
90201-099U3-00 |
from US $2.43 |
||
|
31
|
31
EU0-U7354-00-01 Shim (T=0.1)UR YMUS |
EU0-U7354-00-01 |
from US $3.14 |
||
| replacement | |||||
|
31
|
31
EU0-67354-A0-00 Shim (T=0.1)UR YMUS |
EU0-67354-A0-00 |
from US $2.35 |
||
|
31
|
31
EU0-U7354-00-03 Shim (T=0.3)UR YMUS |
EU0-U7354-00-03 |
from US $3.14 |
||
| replacement | |||||
|
31
|
31
EU0-67354-B0-00 Shim (T=0.3)UR YMUS |
EU0-67354-B0-00 |
from US $2.35 |
||
|
31
|
31
EU0-U7354-00-05 Shim (T=0.5)UR YMUS |
EU0-U7354-00-05 |
from US $3.29 |
||
| replacement | |||||
|
31
|
31
EU0-67354-C0-00 Shim (T=0.5)Ｔ＝０．５ UR YMUS |
EU0-67354-C0-00 |
from US $3.29 |
||
|
31
|
31
EU0-U7354-00-10 Shim (T=1.0)UR YMUS |
EU0-U7354-00-10 |
from US $3.74 |
||
| replacement | |||||
|
31
|
31
EU0-67354-D0-00 Shim (T=1.0)Ｔ＝１．０ UR YMUS |
EU0-67354-D0-00 |
from US $3.74 |
||
|
31
|
31
EU0-U7354-00-20 Shim (T=2.0)UR YMUS |
EU0-U7354-00-20 |
from US $4.94 |
||
| replacement | |||||
|
31
|
31
EU0-67354-E0-00 Shim (T=2.0)UR YMUS |
EU0-67354-E0-00 |
from US $4.94 |
||
|
32
|
32
90119-08835-00 Bolt, With WasherYMUS |
90119-08835-00 |
from US $7.72 |
||
| replacement | |||||
|
32
|
32
901-19088-58-00 Bolt, With WasherYMUS |
901-19088-58-00 |
from US $7.72 |
||
|
33
|
33
F1C-U72C0-00-00
Spacer
|
F1C-U72C0-00-00 |
— | ||
|
34
|
34
90119-069UK-00 Bolt, With WasherYMUS |
90119-069UK-00 |
from US $4.34 |
||
| replacements | |||||
|
34
|
34
901-19068-96-00 Bolt, With WasherYMUS |
901-19068-96-00 |
from US $4.34 |
||
|
34
|
34
901-19069-29-00 Bolt, With WasherYMUS |
901-19069-29-00 |
from US $4.34 |
||
|
35
|
35
F1C-U72C0-10-00 Spacer |
F1C-U72C0-10-00 |
US $21.92 |
||
