Electrical1 Diagram Yamaha CW50 BW'S Next Generation
- Year
- 2001
- Model code
- 5FXM
- Sales region
- Europe (General) (999)
- Engine Capacity
- 50
- Model
- CW50RS
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
5FX-H1960-00-00
Rectifier & Regulator Assy
|
5FX-H1960-00-00 |
— | ||
| replacement | |||||
|
01
|
01
4VV-H1960-01-00 Rectifier Regulator Assy |
4VV-H1960-01-00 |
US $208.94 |
||
|
02
|
02
901-05066-96-00 Bolt, Flange |
901-05066-96-00 |
from US $2.09 |
||
|
03
|
03
4SB-H2021-02-00
Key Set
|
4SB-H2021-02-00 |
— | ||
|
04
|
04
4VV-H2532-00-00 Cap |
4VV-H2532-00-00 |
from US $7.64 |
||
| replacement | |||||
|
04
|
04
1S0-H2552-00-00 Cap, Switch |
1S0-H2552-00-00 |
US $8.12 |
||
|
05
|
05
90109-06851-00 Bolt |
90109-06851-00 |
from US $1.62 |
||
|
06
|
06
5BR-H3350-01-00 Flasher Relay Assy |
5BR-H3350-01-00 |
US $72 |
||
| replacement | |||||
|
06
|
06
5BR-H3350-02-00 Flasher Relay Assy |
5BR-H3350-02-00 |
US $65.11 |
||
|
07
|
07
4CU-H3371-01-00 Horn |
4CU-H3371-01-00 |
US $53.59 |
||
| replacement | |||||
|
07
|
07
4CU-H3371-03-00 Horn |
4CU-H3371-03-00 |
US $53.59 |
||
|
08
|
08
98507-06010-00 Screw, Pan Head |
98507-06010-00 |
from US $0.90 |
||
