Frame Diagram Yamaha CW50 BW'S Next Generation
- Year
- 2001
- Model code
- 5FXM
- Sales region
- Europe (General) (999)
- Engine Capacity
- 50
- Model
- CW50RS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
5FX-F1110-00-00
Frame Comp
(yamaha black) |
5FX-F1110-00-00 |
— | ||
| replacement | |||||
|
01
|
01
5FX-F1110-01-00
Frame Comp
(yamaha black) |
5FX-F1110-01-00 |
— | ||
|
02
|
02
4SB-F174X-00-00 Damper |
4SB-F174X-00-00 |
US $8.51 |
||
|
03
|
03
90105-10063-00 Bolt, Flange |
90105-10063-00 |
from US $8.98 |
||
|
04
|
04
90179-10279-00 Nut |
90179-10279-00 |
from US $1.13 |
||
|
05
|
05
2T4-21481-01-00 Bolt, Engine Mounting 1 |
2T4-21481-01-00 |
from US $4.60 |
||
|
06
|
06
95617-10100-00 Nut, U |
95617-10100-00 |
from US $3.74 |
||
|
07
|
07
5FX-F1410-00-00
Engine Bracket Comp
|
5FX-F1410-00-00 |
— | ||
|
08
|
08
2T4-2139X-00-00 Damper |
2T4-2139X-00-00 |
US $1.73 |
||
| replacement | |||||
|
08
|
08
3WG-F139X-00-00
Damper
|
3WG-F139X-00-00 |
— | ||
|
09
|
09
90501-290K2-00 Spring, Compression |
90501-290K2-00 |
US $2.54 |
||
|
10
|
10
4VA-F1232-00-00
Reinforcement, Tail
|
4VA-F1232-00-00 |
— | ||
|
11
|
11
958-17080-16-00 Bolt, Flange |
958-17080-16-00 |
from US $0.90 |
||
| replacement | |||||
|
11
|
11
901-0508X-15-00
Blt,hex,1/4-20X5/8
|
901-0508X-15-00 |
— | ||
|
12
|
12
4SB-F7452-00-00
Bracket, Footrest 1
(ur for f/b/prt/gb) |
4SB-F7452-00-00 |
— | ||
|
13
|
13
90111-08X00-00 Bolt Hex, Socket Button(for f/b/prt/gb) |
90111-08X00-00 |
US $6.46 |
||
