Meter Diagram Yamaha CW50 BW'S Next Generation
- Year
- 2001
- Model code
- 5FXM
- Sales region
- Europe (General) (999)
- Engine Capacity
- 50
- Model
- CW50RS
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
5FX-H3510-20-00
Speedometer Assy
(ur for f/sp/b/prt) |
5FX-H3510-20-00 |
— | ||
|
01
|
01
5FX-H3510-30-00
Speedometer Assy
(ur for gb) |
5FX-H3510-30-00 |
— | ||
|
02
|
02
NJ9-H4744-00-01
Bulb (12V-1.2W)
|
NJ9-H4744-00-01 |
— | ||
| replacement | |||||
|
02
|
02
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
03
|
03
4SB-H353K-00-00
Glass Plate
|
4SB-H353K-00-00 |
— | ||
|
04
|
04
5BR-H3534-00-00
Socket. Wire Harness
|
5BR-H3534-00-00 |
— | ||
|
05
|
05
90167-05078-00 Screw, Tapping |
90167-05078-00 |
from US $1.35 |
||
|
06
|
06
4SB-H3550-02-00 Speedometer Cable Assy |
4SB-H3550-02-00 |
US $26.29 |
||
| replacement | |||||
|
06
|
06
4SB-H3550-03-00 Speedometer Cable Assy |
4SB-H3550-03-00 |
US $26.29 |
||
