A/c condenser, piping (SWITCH & HOSE) Diagram Mitsubishi PAJERO/MONTERO
- Year
- 2000 - 2006
- Sales region
- EUR
- Note
- GLS(NSS4),5FM/T LHD
- transmission
- 5FM/T
- grade
- GLS
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
82162D
|
82162D
MB439757
SWITCH, WATER TEMPERATURE
|
MB439757 |
— | ||
|
82162E
|
82162E
MB439918 SWITCH, WATER TEMPERATURE |
MB439918 |
US $61.83 |
||
|
87058B
|
87058B
MR513378
INSULATOR,A/C
|
MR513378 |
— | ||
|
87107
|
87107
MB878021 VALVE,A/C VACUUM SOLENOID |
MB878021 |
US $69.26 |
||
|
87205B
|
87205B
MS632592 HOSE, EMISSION VACUUM CONTROL EQUIP3x2000 |
MS632592 |
US $54.72 |
||
|
87205C
|
87205C
MS632792 HOSE, EMISSION SOLENOID VALVE3x2000 |
MS632792 |
US $54.04 |
||
|
87408
|
87408
MB958688 ACTUATOR, A/C ENG IDLE CONTROL |
MB958688 |
US $139.21 |
||
| replacement | |||||
|
87408
|
87408
5826615120
ACTUATOR, A/C ENG IDLE CONTROL
|
5826615120 |
— | ||
|
87535B
|
87535B
MS440502 NUT, FUEL TANKWasher assembled,6 |
MS440502 |
from US $1.74 |
||
|
87544
|
87544
MD001843 CLAMP, CARB INR |
MD001843 |
US $2.96 |
||
|
87547D
|
87547D
MS240021 BOLT, FUEL FILLER LID PANELWasher assembled,6x16 |
MS240021 |
from US $0.80 |
||
|
87547E
|
87547E
MS240022 BOLT, CRUISE CONTROL EQUIPWasher assembled,6x20 |
MS240022 |
US $2.19 |
||
|
87548
|
87548
MB249338 BAND, ROCKER COVERL=129.5 |
MB249338 |
US $2.87 |
||
