Heating & Air Conditioning - Cooler Piping ([05.1987 - ] (8705- )) Diagram Toyota COROLLA
- Year
- 1987 - 1989
- Sales region
- Japan
- Frame
- AE92
- ENGINE
- 4AGE
- TRANSMISSION
- MTM
- Model
- COROLLA LEVIN/COUPE
- From
- 05.1987
- To
- 05.1989
- Gear Shift Type
- 5F
- Vehicle Model
- Corolla Levin
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88453A
|
88453A
88453-12050 Fan, Cooling (For Condenser)[05.1987 - 05.1988] AE91..L; AE9#..G,GT,GTAPX,GTV,GTZ,ZI |
88453-12050 |
US $111.56 |
||
|
88454A
|
88454A
88454-12100
Shroud, Fan
[05.1987 - 05.1988] AE91..L; AE9#..G,GT,GTAPX,GTV,GTZ,ZI |
88454-12100 |
— | ||
|
88550
|
88550
88550-12120 Motor Assy, Blower (For Condenser)[05.1987 - 05.1988] AE91..L; AE9#..G,GT,GTAPX,GTV,GTZ,ZI |
88550-12120 |
US $232.96 |
||
|
88590
|
88590
88590-12170
Blower Assy, W/shroud
[05.1987 - 12.1987] AE91..L; AE9#..G,GT,GTAPX,GTV,GTZ,ZI |
88590-12170 |
— | ||
|
88596C
|
88596C
88723-12020
Plate, Caution, No.2
[05.1987 - 08.1987] AE9# |
88723-12020 |
— | ||
|
8846714070
|
8846714070
88467-14070
Insulator (For Power Take-Off Cable Bracket)
|
88467-14070 |
— | ||
|
8846720040
|
8846720040
88467-20040
Insulator, Cooler Condenser Mounting
|
88467-20040 |
— | ||
|
8846730270
|
8846730270
88467-30270 Cushion, Cooler Condenser, No.1 |
88467-30270 |
from US $1.75 |
||
|
8868812780
|
8868812780
88688-12780
Bracket, Cooler Diaphragm
|
88688-12780 |
— | ||
|
8889212180
|
8889212180
88892-12180
Net, Fan Shroud
|
88892-12180 |
— | ||
|
9009904376
|
9009904376
90099-04376
New Genuine Part
|
90099-04376 |
— | ||
|
9011906336
|
9011906336
90119-06336 SCREW |
90119-06336 |
US $1.43 |
||
|
9015960128
|
9015960128
90159-60128 New Genuine Part |
90159-60128 |
US $2.15 |
||
|
9017906032
|
9017906032
90179-06032
Direct
|
90179-06032 |
— | ||
| replacement | |||||
|
9017906032
|
9017906032
90179-06274 Nut |
90179-06274 |
from US $0.70 |
||
