Throttle Link & Valve Lever (Atm) ([08.1988 - ] A340E (8808- )) Diagram Toyota CRESSIDA/ CRESSIDA WAGON
- Year
- 1988 - 1992
- Sales region
- U.S.A.
- Frame
- MX83
- grade
- GLX
- body
- SED
- ENGINE
- 7MGE
- TRANSMISSION
- ATM
- DESTINATION
- CND
- Model
- CRESSIDA
- From
- 08.1988
- To
- 07.1992
- Gear Shift Type
- 4FC
- Vehicle Model
- Cressida
- Fuel Induction
- TWC
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35520
|
35520
35520-22080
Cable Assy, Throttle
[08.1988 - 07.1992] MX83 |
35520-22080 |
— | ||
|
35520B
|
35520B
90301-09012 Ring, O (For Automatic Transmission Case Plug)[08.1988 - 07.1992] MX83 |
90301-09012 |
US $3.94 |
||
|
35523
|
35523
35523-30090 Clamp, Throttle Cable[08.1988 - 07.1992] MX83 |
35523-30090 |
US $5.82 |
||
|
35525
|
35525
35525-14070 Bracket, Throttle CableTHROTTLE CABLE [08.1988 - 07.1992] MX83 |
35525-14070 |
US $18.35 |
||
|
91611F0812
|
91611F0812
91611-F0812
New Genuine Part
|
91611-F0812 |
— | ||
| replacement | |||||
|
91611F0812
|
91611F0812
90119-08846 BOLT WWASHER |
90119-08846 |
US $1.25 |
||
|
91651F0825
|
91651F0825
91651-F0825 New Genuine Part |
91651-F0825 |
US $2.18 |
||
| replacement | |||||
|
91651F0825
|
91651F0825
91651-G0825 New Genuine Part |
91651-G0825 |
US $1.16 |
||
|
9017908025
|
9017908025
90179-08025 Nut, Cap(For Cylinder Head Cover) |
90179-08025 |
from US $0.88 |
||
|
9165140610
|
9165140610
91651-40610 RIVET |
91651-40610 |
US $2.87 |
||
|
9622110710
|
9622110710
96221-10710 Clamp, Throttle Cable, No.2 |
96221-10710 |
US $2.18 |
||
