Rear Axle Shaft & Hub ([08.1988 - ] (8808- )MX83) Diagram Toyota CRESSIDA/ CRESSIDA WAGON
- Year
- 1988 - 1993
- Sales region
- General
- Frame
- MX83
- grade
- GLX
- body
- SED
- ENGINE
- 7MGE
- TRANSMISSION
- ATM
- DESTINATION
- ARL
- Model
- CRESSIDA
- From
- 08.1988
- To
- 02.1993
- Gear Shift Type
- 4FC
- Vehicle Model
- Cressida
- Driver's Position
- RHD
- Fuel Induction
- TWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04438D
|
04438D
04437-22110 Boot Kit, Rear Drive Shaft Inboard Joint[08.1988 - 02.1993] MX83 |
04437-22110 |
US $90.27 |
||
|
04438E
|
04438E
04437-30030 Boot Kit, Rear Drive Shaft Inboard Joint[08.1988 - 02.1993] MX83 |
04437-30030 |
US $109.88 |
||
|
42340
|
42340
42340-22040 Shaft Assy, Rear Drive[08.1988 - 02.1993] MX83 |
42340-22040 |
US $796.43 |
||
| replacements | |||||
|
42340
|
42340
42340-22090 Shaft Assy, Rear Drive[08.1988 - 02.1993] MX83 |
42340-22090 |
US $796.43 |
||
|
42340
|
42340
42428-24010 Plate, Rear Axle Lock Nut[08.1988 - 02.1993] MX83 |
42428-24010 |
from US $6.53 |
||
|
42340
|
42340
90179-26006 Nut (For Rear Axle Shaft)[08.1988 - 02.1993] MX83 |
90179-26006 |
from US $3 |
||
|
42341A
|
42341A
90520-29028 Ring, Snap (For Rear Drive Shaft)[08.1988 - 02.1993] MX83 INNER |
90520-29028 |
from US $1.79 |
||
|
42341A
|
42341A
90521-34005 Ring, Snap (For Rear Drive Shaft)[08.1988 - 02.1993] MX83 OUTER |
90521-34005 |
from US $1.42 |
||
|
42345
|
42345
90949-01221 Clamp, Rear Drive Shaft Boot[08.1988 - 02.1993] MX83 |
90949-01221 |
US $2.33 |
||
|
42346
|
42346
90949-01290 Clamp (For Rear Drive Shaft Outboard Joint Boot)[08.1988 - 02.1993] MX83 |
90949-01290 |
US $3.67 |
||
|
42347
|
42347
90949-01222 Clamp (For Rear Drive Shaft Outboard Joint Boot)[08.1988 - 02.1993] MX83 |
90949-01222 |
US $3.05 |
||
|
42360
|
42360
42360-22030 Joint Assy, Rear Drive Shaft Inboard[08.1988 - 02.1993] MX83 |
42360-22030 |
US $422.24 |
||
| replacement | |||||
|
42360
|
42360
42360-26010 Joint Assy, Rear Drive Shaft Inboard[08.1988 - 02.1993] MX83 |
42360-26010 |
from US $267.74 |
||
|
42370
|
42370
42370-19035 Shaft Assy, Rear Drive Outboard Joint[08.1988 - 02.1993] MX83 |
42370-19035 |
US $556.19 |
||
| replacements | |||||
|
42370
|
42370
42370-19036 Shaft Assy, Rear Drive Outboard Joint[08.1988 - 02.1993] MX83 |
42370-19036 |
US $554.74 |
||
|
42370
|
42370
42428-24010 Plate, Rear Axle Lock Nut[08.1988 - 02.1993] MX83 |
42428-24010 |
from US $6.53 |
||
|
42370
|
42370
90179-26006 Nut (For Rear Axle Shaft)[08.1988 - 02.1993] MX83 |
90179-26006 |
from US $3 |
||
|
9017010191
|
9017010191
90170-10191 Nut(For Rear Drive Shaft) |
90170-10191 |
US $1.97 |
||
|
9020110068
|
9020110068
90201-10068 New Genuine Part |
90201-10068 |
US $1.61 |
||
