Radiator & Water Outlet ([09.2002 - ] (0209- )14B) Diagram Toyota DYNA/ TOYOACE
- Year
- 2002 - 2006
- Sales region
- General
- Frame
- BU303
- ENGINE
- 14B
- DESTINATION
- GEN
- DECK
- TS
- From
- 12.2002
- To
- 10.2006
- Loading Capacity
- 55T
- Driver's Position
- RHD
- Fuel Induction
- DSL
- Building Condition
- IV3
- Rear Tire
- WT
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
16261
|
16261
16261-56012 Hose, Water By-Pass[09.2002 - 12.2006] 14B..BU303,343 |
16261-56012 |
from US $10.16 |
||
|
16261A
|
16261A
90467-28005 Clamp Or Clip, Hose(For Water By-Pass Hose)[09.2002 - 12.2006] 14B,15BFTE..BU30#,34# |
90467-28005 |
US $5.02 |
||
|
16331
|
16331
16331-58080 Outlet, Water[12.2002 - 10.2006] 15BFTE..XZU300,320,330,340; 14B,15BFTE..BU30#,34#..ARL,GEN |
16331-58080 |
from US $52.01 |
||
|
16331A
|
16331A
90916-03102 Thermostat[09.2002 - 12.2006] 14B,15BFTE..BU30#,34# |
90916-03102 |
from US $20.51 |
||
|
16331B
|
16331B
90341-12006 Plug(For Water Outlet)[12.2002 - 10.2006] 14B..BU303,343..GEN |
90341-12006 |
US $4.54 |
||
|
16331F
|
16331F
16401-67150 Cap Sub-Assy(For Water Outlet)[12.2002 - 10.2006] 15BFTE..XZU300,320,330,340; 14B,15BFTE..BU30#,34#..ARL,GEN |
16401-67150 |
from US $16.97 |
||
|
16331Q
|
16331Q
90345-54005 Plug, W/head Taper Screw, No.1[09.2002 - 12.2006] 14B..BU303,343 |
90345-54005 |
from US $3.90 |
||
|
16333
|
16333
16333-58080 Housing, Water Outlet[09.2002 - 12.2006] 14B..BU303,343 |
16333-58080 |
from US $61.13 |
||
|
16333A
|
16333A
92112-60832 Bolt, Stud(For Water Outlet Housing)[09.2002 - 12.2006] 14B,15BFTE..BU30#,34# |
92112-60832 |
US $3.76 |
||
|
16341
|
16341
16341-56030 Gasket, Water Outlet[09.2002 - 12.2006] 14B,15BFTE..BU30#,34# |
16341-56030 |
from US $2.57 |
||
|
16343
|
16343
16343-56023 Gasket, Water Outlet Housing[09.2002 - 12.2006] 14B,15BFTE..BU30#,34# |
16343-56023 |
from US $3.37 |
||
|
16381
|
16381
16381-58120 Bar, Fan Belt Adjusting[09.2002 - 12.2006] 14B..BU303,343 |
16381-58120 |
US $26.79 |
||
|
16572
|
16572
16572-56091 Hose, Radiator, Outlet[12.2002 - 10.2006] 14B..BU303,343..GEN NO.2 |
16572-56091 |
from US $10.39 |
||
|
16572
|
16572
16572-58170 Hose, Radiator, Outlet[12.2002 - 10.2006] 14B..BU303,343..RHD..GEN NO.1 |
16572-58170 |
US $29.27 |
||
| replacement | |||||
|
16572
|
16572
16572-58171 Hose, Radiator, Outlet[12.2002 - 10.2006] 14B..BU303,343..RHD..GEN NO.1 |
16572-58171 |
US $24.17 |
||
|
16572C
|
16572C
90466-41003 Clip, Radiator Hose, No.1[09.2002 - 12.2006] 14B..BU303,343 RADIATOR PIPE SIDE |
90466-41003 |
from US $8.48 |
||
|
16572C
|
16572C
90467-48003 Clamp Or Clip, Hose(For Radiator Outlet No.1)[09.2002 - 12.2006] 14B..BU303,343 WATER PUMP SIDE |
90467-48003 |
from US $5.25 |
||
|
16577
|
16577
16577-58040 Pipe, Radiator, No.7[09.2002 - 12.2006] 14B..BU303,343 |
16577-58040 |
US $72.16 |
||
|
91651B0825
|
91651B0825
91651-B0825 Bolt, Hexagon(For Steering Column Bracket) |
91651-B0825 |
from US $0.84 |
||
|
9011908B05
|
9011908B05
90119-08B05 New Genuine Part |
90119-08B05 |
US $2.51 |
||
|
9011910409
|
9011910409
90119-10409 New Genuine Part |
90119-10409 |
US $1.97 |
||
|
9017908040
|
9017908040
90179-08040 Nut, Cap(For Cylinder Head Cover) |
90179-08040 |
from US $1.03 |
||
|
9043012221
|
9043012221
90430-12221 Gasket |
90430-12221 |
from US $1.07 |
||
