Power Take-Off Case & Gear ([07.1999 - ] (9907- )XZU30#,330,34#) Diagram Toyota DYNA/ TOYOACE
- Year
- 1999 - 2002
- Sales region
- General
- Frame
- XZU340
- ENGINE
- 15BFTE
- TRANSMISSION
- MTM
- From
- 07.1999
- To
- 12.2002
- Loading Capacity
- 40T
- Rear Tire
- WT
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
27679C
|
27679C
27679-78040 Bracket, Power Take-Off Solenoid[07.1999 - 05.2000] 15BFTE..XZU300,330,340 |
27679-78040 |
US $15.87 |
||
| replacement | |||||
|
27679C
|
27679C
27679-78041 Bracket, Power Take-Off Solenoid[07.1999 - 05.2000] 15BFTE..XZU300,330,340 |
27679-78041 |
US $9.76 |
||
|
27679C
|
27679C
27679-78041 Bracket, Power Take-Off Solenoid[05.2000 - 12.2002] S05C,15BFTE..XZU30#,330,34# |
27679-78041 |
US $9.76 |
||
|
27690J
|
27690J
27690-78030 Solenoid Assy, Power Take-Off[07.1999 - 11.2001] S05C,15BFTE..XZU30#,320,330,34# |
27690-78030 |
US $187.82 |
||
| replacements | |||||
|
27690J
|
27690J
27690-78032 Solenoid Assy, Power Take-Off[07.1999 - 11.2001] S05C,15BFTE..XZU30#,320,330,34# |
27690-78032 |
US $154.16 |
||
|
27690J
|
27690J
27690-78080 Solenoid Assy, Power Take-Off[07.1999 - 11.2001] S05C,15BFTE..XZU30#,320,330,34# |
27690-78080 |
US $180.80 |
||
|
27690J
|
27690J
27690-78031 Solenoid Assy, Power Take-Off[11.2001 - 12.2002] S05C,15BFTE..XZU30#,320,330,34# |
27690-78031 |
US $183.46 |
||
| replacements | |||||
|
27690J
|
27690J
27690-78032 Solenoid Assy, Power Take-Off[11.2001 - 12.2002] S05C,15BFTE..XZU30#,320,330,34# |
27690-78032 |
US $154.16 |
||
|
27690J
|
27690J
27690-78080 Solenoid Assy, Power Take-Off[11.2001 - 12.2002] S05C,15BFTE..XZU30#,320,330,34# |
27690-78080 |
US $180.80 |
||
|
44754H
|
44754H
44754-37110 Bracket, Vacuum Tube[07.1999 - 12.2002] XZU30#,330,34# |
44754-37110 |
US $5.53 |
||
|
44763E
|
44763E
44763-37160 Tube, Hose To Hose, No.1[07.1999 - 12.2002] XZU300,330,34# |
44763-37160 |
US $44.55 |
||
|
44763F
|
44763F
44763-37220 Tube, Hose To Hose, No.2[07.1999 - 12.2002] XZU30#,330,34# |
44763-37220 |
US $39.89 |
||
|
44763H
|
44763H
44771-37450 Hose, Vacuum Brake[07.1999 - 12.2002] XZU30#,330,34# |
44771-37450 |
US $9.46 |
||
|
44771G
|
44771G
44771-37290 Hose, Vacuum Tube Connector, No.1[07.1999 - 12.2002] XZU30#,330,34# |
44771-37290 |
US $19.80 |
||
|
44771H
|
44771H
95446-09300 Hose, Solenoid To Vacuum Tube[07.1999 - 12.2002] XZU30#,330,34# |
95446-09300 |
US $11.65 |
||
|
44779J
|
44779J
44776-37180 Hose, Vacuum Tube Connector[07.1999 - 12.2002] XZU30#,330,34# |
44776-37180 |
US $8.59 |
||
|
4737137040
|
4737137040
47371-37040 Clamp(For Clutch Tube) |
47371-37040 |
US $5.73 |
||
|
9011908676
|
9011908676
90119-08676 BOLT WWASHER |
90119-08676 |
US $2.15 |
||
|
9413000802
|
9413000802
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.84 |
||
|
9613341500
|
9613341500
96133-41500 Clamp Or Clip(For Air Hose, No.5) |
96133-41500 |
from US $2.32 |
||
