Rear Spring & Shock Absorber ([12.1982 - ] (8212- )10S) Diagram Toyota HIACE
- Year
- 1982 - 1985
- Sales region
- Japan
- Frame
- YH61G
- grade
- STD
- body
- WG
- Roof
- SRF
- ENGINE
- 3YU
- TRANSMISSION
- MTM
- Model
- HIACE VAN/WAGON/COMMUTER BUS
- From
- 12.1982
- To
- 08.1985
- Gear Shift Type
- 5H
- Seating Capacity
- 10S
- Vehicle Model
- Hiace Van,Wagon
- Fuel Induction
- CBR
- Rear Tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48210
|
48210
48210-26310 Spring Assy, Rear Rh[12.1982 - 08.1985] LH6#,YH61..10S |
48210-26310 |
US $595.50 |
||
|
48210
|
48210
48210-26311 Spring Assy, Rear Rh[08.1985 - 08.1987] LH61,YH61..10S |
48210-26311 |
US $500.86 |
||
|
48210C
|
48210C
90389-14007 Bush(For Rear Spring Leaf)[12.1982 - 08.1987] LH60,61,YH61..10S; LH5#,6#,7#,YH5#,6#,71..(COM,V)..ST |
90389-14007 |
from US $18.65 |
||
|
48211
|
48211
48201-26310 Leaf, Rear Spring, No.1[12.1982 - 08.1985] LH6#,YH61..10S |
48201-26310 |
US $318.86 |
||
|
48211
|
48211
48201-26311 Leaf, Rear Spring, No.1[08.1985 - 08.1987] LH61,YH61..10S |
48201-26311 |
US $203.84 |
||
| replacement | |||||
|
48211
|
48211
48201-26250
Leaf, Rear Spring, No.1
[08.1985 - 08.1987] LH61,YH61..10S |
48201-26250 |
— | ||
|
48212
|
48212
48202-26310 Leaf, Rear Spring, No.2[12.1982 - 08.1985] LH6#,YH61..10S |
48202-26310 |
US $283.92 |
||
|
48212
|
48212
48212-26311 Leaf, Rear Spring, No.2[08.1985 - 08.1987] LH61,YH61..10S |
48212-26311 |
US $154.34 |
||
| replacement | |||||
|
48212
|
48212
48212-26330 Leaf, Rear Spring, No.2[08.1985 - 08.1987] LH61,YH61..10S |
48212-26330 |
US $145.60 |
||
|
48213
|
48213
48202-26311 Leaf, Rear Spring, No.3[08.1985 - 08.1987] LH61,YH61..10S |
48202-26311 |
US $106.29 |
||
|
48214
|
48214
48214-26311 Leaf, Rear Spring, No.4[08.1985 - 08.1987] LH61,YH61..10S |
48214-26311 |
US $47.76 |
||
|
48220
|
48220
48210-26310 Spring Assy, Rear Rh[12.1982 - 08.1985] LH6#,YH61..10S |
48210-26310 |
US $595.50 |
||
|
48220
|
48220
48210-26311 Spring Assy, Rear Rh[08.1985 - 08.1987] LH61,YH61..10S |
48210-26311 |
US $500.86 |
||
|
48241
|
48241
48241-28010 Clip, Rear Spring, No.1[12.1982 - 08.1985] LH6#,YH61..10S |
48241-28010 |
US $8.59 |
||
|
48242
|
48242
48242-28031
Clip, Rear Spring, No.2
[12.1982 - 08.1985] LH6#,YH61..10S |
48242-28031 |
— | ||
|
48243
|
48243
48241-28011
Clip, Rear Spring, No.2
[12.1982 - 08.1985] LH6#,YH61..10S |
48241-28011 |
— | ||
|
48243A
|
48243A
48243-28032
Stay, Rear Spring Clip Damper
[12.1982 - 08.1985] LH6#,YH61..10S |
48243-28032 |
— | ||
|
48247
|
48247
48247-26310 Bolt, Rear Spring, Center[12.1982 - 08.1985] LH6#,YH61..10S |
48247-26310 |
US $7.86 |
||
|
48247
|
48247
48247-26311 Bolt, Rear Spring, Center[08.1985 - 08.1987] LH61,YH61..10S |
48247-26311 |
US $4.95 |
||
|
48252
|
48252
48252-26070 Silencer, Front Spring[12.1982 - 08.1987] LH60,61,YH61..10S |
48252-26070 |
from US $2.13 |
||
|
48253
|
48253
48251-28030 Inter Leaf, Rear Spring, No.2(For Rr Spring No.1 Leaf Shim)[12.1982 - 08.1987] LH60,61,YH61..10S |
48251-28030 |
US $7.86 |
||
|
48253A
|
48253A
48255-26120 Mass Damper, Rear Spring, No.1[12.1982 - 08.1985] LH6#,YH61..10S |
48255-26120 |
US $16.16 |
||
|
48284
|
48284
48299-28010 Nut, Rear Spring Center Bolt[12.1982 - 08.1987] LH60,61,YH61..10S; LH5#,6#,7#,YH5#,6#,71..COM,V |
48299-28010 |
US $3.35 |
||
|
9511100820
|
9511100820
95111-00820 New Genuine Part |
95111-00820 |
US $1.75 |
||
|
9511101036
|
9511101036
95111-01036 New Genuine Part |
95111-01036 |
US $1.75 |
||
|
9511101038
|
9511101038
95111-01038 New Genuine Part |
95111-01038 |
US $1.31 |
||
