Electronic Fuel Injection System ([05.2015 - ] COWL (1505- )GGN12#,135) Diagram Toyota HILUX/4RUNNER TRUCK
- Year
- 2015 - 2018
- Sales region
- General
- Frame
- GGN120
- ENGINE
- 1GRFE
- TRANSMISSION
- ATM
- DESTINATION
- ARL
- CAB
- THDCB
- Model
- HILUX
- From
- 05.2015
- Gear Shift Type
- 6FC
- Vehicle Model
- Hilux
- Model Mark
- S
- Driver's Position
- RHD
- Fuel Induction
- HTWC
- Building Condition
- CBU
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
89661
|
89661
89666-0KJ00
Computer, Engine Control
[05.2015 - 01.2017] GGN120 |
89666-0KJ00 |
— | ||
| replacement | |||||
|
89661
|
89661
89666-0KJ01
Computer, Engine Control
[05.2015 - 01.2017] GGN120 |
89666-0KJ01 |
— | ||
|
89661
|
89661
89666-0KJ01
Computer, Engine Control
[02.2017 -] GGN120 |
89666-0KJ01 |
— | ||
|
89667
|
89667
89667-0K100
Bracket, Engine Control Computer
[05.2015 -] GGN12#,TGN121,126,136..RHD..(ARL,GEN,TH); GGN125,135,TGN110,120,136..IDN,SA MADE IN THAILAND |
89667-0K100 |
— | ||
|
89668
|
89668
89668-0K180
Bracket, Engine Control Computer, No.2
[05.2015 -] GGN12#,135..RHD |
89668-0K180 |
— | ||
|
90105T0066
|
90105T0066
90105-T0066
BOLT FLANGE
|
90105-T0066 |
— | ||
|
90153T0001
|
90153T0001
90153-T0001
BOLT
|
90153-T0001 |
— | ||
|
90178T0018
|
90178T0018
90178-T0018 NUT FLANGE |
90178-T0018 |
US $0.76 |
||
|
9017906323
|
9017906323
90179-06323 Nut |
90179-06323 |
US $1.97 |
||
|
9167380616
|
9167380616
91673-80616 Bolt, W/washer |
91673-80616 |
from US $0.64 |
||
