Clutch Pedal & Flexible Hose ([10.1998 - ] (9810- )KF60,8#,YF60,80..5F..LHD) Diagram Toyota INNOVA/ KIJANG/ REVO/ UNSER/ ZACE
- Year
- 1998 - 2002
- Sales region
- General
- Frame
- KF80
- grade
- GLX
- ENGINE
- 7KE
- TRANSMISSION
- MTM
- DESTINATION
- PHL
- DECK
- LUB
- CAB
- SRF
- Model
- REVO
- From
- 10.1998
- To
- 11.2002
- Gear Shift Type
- 5F
- Vehicle Model
- REVO
- Driver's Position
- LHD
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-0B021
Pedal Sub-Assy, Clutch
[10.1998 - 11.2002] KF80..5F..PHL |
31301-0B021 |
— | ||
|
31301A
|
31301A
90905-06035 Spring(For Clutch Pedal)[10.1998 - 06.2003] KF60,80,YF60,80..5F..LHD |
90905-06035 |
US $3.79 |
||
|
31301B
|
31301B
90541-06036 Cushion, No.1(For Clutch Pedal)[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90541-06036 |
from US $0.94 |
||
| replacement | |||||
|
31301B
|
31301B
90541060361
CUSHION
[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90541060361 |
— | ||
|
31301C
|
31301C
90386-13015 Bush(For Clutch Pedal)[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90386-13015 |
from US $0.64 |
||
|
31301F
|
31301F
90101-10369 Bolt(For Clutch Pedal Stopper)[12.1996 - 06.2003] KF82,LF82..5F..RHD;KF60,7#,80,LF6#,7#,80,81,85,RZF71,80,81,85,YF60,80..MTM |
90101-10369 |
from US $1.31 |
||
|
31301J
|
31301J
94130-61000 Nut(For Clutch Pedal Stopper)[12.1996 - 06.2003] KF82,LF82..5F..RHD;KF60,7#,80,LF6#,7#,80,81,85,RZF71,80,81,85,YF60,80..MTM |
94130-61000 |
from US $0.76 |
||
|
31301S
|
31301S
90541-06036 Cushion, No.1(For Clutch Pedal)[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90541-06036 |
from US $0.94 |
||
| replacement | |||||
|
31301S
|
31301S
90541060361
CUSHION
[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90541060361 |
— | ||
|
31321
|
31321
31321-14010 Pedal Pad[10.1998 - 11.2002] KF80,LF80,RZF81..5F..PHL |
31321-14010 |
US $5.73 |
||
|
31324
|
31324
90101-10015 Shaft, Clutch Pedal[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90101-10015 |
from US $1.07 |
||
| replacement | |||||
|
31324
|
31324
90101100151
Bolt, Hexagon
[10.1998 - 06.2003] KF60,80,LF61,80,81,85,RZF81,85,YF60,80..5F..LHD |
90101100151 |
— | ||
|
31324A
|
31324A
90387-10003 Collar, Clutch Pedal Shaft[12.1996 - 06.2003] KF82,LF82..5F..RHD;KF60,7#,80,LF6#,7#,80,81,85,RZF71,80,81,85,YF60,80..MTM |
90387-10003 |
from US $3.94 |
||
|
31453A
|
31453A
90240-08006 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[12.1996 - 06.2003] KF82,LF82..5F..RHD;KF60,7#,80,LF6#,7#,80,81,85,RZF71,80,81,85,YF60,80..MTM L=23.5 |
90240-08006 |
from US $2.87 |
||
|
31453B
|
31453B
90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)[12.1996 - 06.2003] KF82,LF82..5F..RHD;KF60,7#,80,LF6#,7#,80,81,85,RZF71,80,81,85,YF60,80..MTM |
90386-08002 |
from US $3.22 |
||
|
55107A
|
55107A
55107-0B030
Support Sub-Assy, Clutch Pedal
[10.1998 - 11.2002] KF80..5F..PHL |
55107-0B030 |
— | ||
|
91651B0825
|
91651B0825
91651-B0825 Bolt, Hexagon(For Steering Column Bracket) |
91651-B0825 |
from US $0.84 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
||
|
9163160816
|
9163160816
91631-60816 BOLT |
91631-60816 |
from US $1.07 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.76 |
||
|
9453101000
|
9453101000
94531-01000 WASHER |
94531-01000 |
from US $1.61 |
||
|
9461311001
|
9461311001
94613-11001 WASHER |
94613-11001 |
US $2.15 |
||
