Front Spring & Shock Absorber ([08.2013 - ] KDSS (0908-1308)GRJ150 ; (1308- )GRJ150..ATM ; (13 08- )GRJ150..6F..GEN) Diagram Toyota LAND CRUISER PRADO
- Year
- 2015 - 2018
- Sales region
- General
- Frame
- GRJ150
- ENGINE
- 1GRFE
- TRANSMISSION
- ATM
- DESTINATION
- GEN
- Model
- LAND CRUISER PRADO 150
- From
- 06.2015
- Gear Shift Type
- 6FC
- No.of Doors
- 5D
- Vehicle Model
- Land Cruiser Prado
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31478S
|
31478S
31478-60020 Cap, Bleeder Plug(For Front Suspension Control)BLEEDER PLUG(FOR FRONT SUSPENSION CONTROL) [06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
31478-60020 |
US $0.54 |
||
|
48811
|
48811
48811-60320 Bar, Stabilizer, FrontSTABILIZER, FRONT [06.2015 -] GRJ150 |
48811-60320 |
from US $165.98 |
||
|
48811
|
48811
48811-60390 Bar, Stabilizer, Front[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48811-60390 |
US $372.15 |
||
|
48815D
|
48815D
48815-60380 Bush, Front Stabilizer Bar, No.1[06.2015 -] GDJ150,GRJ150,KDJ150,LJ150,TRJ15# |
48815-60380 |
from US $12.75 |
||
|
48815D
|
48815D
48815-60390 Bush, Front Stabilizer Bar, Rh[06.2015 -] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48815-60390 |
from US $13.83 |
||
|
48815D
|
48815D
48815-60410
Bush, Front Stabilizer Bar, Rh
[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS) |
48815-60410 |
— | ||
|
48815E
|
48815E
48815-60380 Bush, Front Stabilizer Bar, No.1[06.2015 -] GDJ150,GRJ150,KDJ150,LJ150,TRJ15# |
48815-60380 |
from US $12.75 |
||
|
48815E
|
48815E
48815-60390 Bush, Front Stabilizer Bar, Rh[06.2015 -] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48815-60390 |
from US $13.83 |
||
|
48815E
|
48815E
48815-60410
Bush, Front Stabilizer Bar, Rh
[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS) |
48815-60410 |
— | ||
|
48820
|
48820
48820-60090 Link Assy, Front StabilizerFRONT STABILIZER [06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48820-60090 |
from US $45.88 |
||
|
48827D
|
48827D
48827-60070 Protector, Front Stabilizer TubeFRONT STABILIZER TUBE [06.2015 -] GRJ150..6FC..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48827-60070 |
US $51.69 |
||
|
48828C
|
48828C
48828-60050 Bracket, Front Stabilizer, Lower RhFRONT STABILIZER, LOWER RH [06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48828-60050 |
US $19.42 |
||
|
48828D
|
48828D
48828-60050 Bracket, Front Stabilizer, Lower RhFRONT STABILIZER, LOWER RH [06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48828-60050 |
US $19.42 |
||
|
48836
|
48836
48836-60130 Bracket, Front Stabilizer End, Rh[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48836-60130 |
US $10.83 |
||
|
48837
|
48837
48837-60080 Bracket, Front Stabilizer End, Lh[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48837-60080 |
from US $10.83 |
||
|
48849A
|
48849A
48849-60040
Bush, Front Stabilizer Link
[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48849-60040 |
— | ||
| replacement | |||||
|
48849A
|
48849A
48849-60041 Bush, Front Stabilizer Link[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48849-60041 |
from US $10.88 |
||
|
48849B
|
48849B
48849-60040
Bush, Front Stabilizer Link
[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48849-60040 |
— | ||
| replacement | |||||
|
48849B
|
48849B
48849-60041 Bush, Front Stabilizer Link[06.2015 -] GRJ150..6FC..GEN;KDJ150..LHD..GEN GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&STABILIZER-WITH(KDSS); GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48849-60041 |
from US $10.88 |
||
|
48870
|
48870
48007-60021
Cylinder Assy, Front Stabilizer W/tube
[06.2015 - 12.2015] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60021 |
— | ||
| replacements | |||||
|
48870
|
48870
48007-60022
Cylinder Assy, Front Stabilizer W/tube
[06.2015 - 12.2015] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60022 |
— | ||
| replacement | |||||
|
48870
|
48870
48007-60023 Cylinder Assy, Front Stabilizer W/tube[06.2015 - 12.2015] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60023 |
from US $1,090.58 |
||
|
48870
|
48870
48007-60023 Cylinder Assy, Front Stabilizer W/tube[06.2015 - 12.2015] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60023 |
from US $1,090.58 |
||
|
48870
|
48870
48007-60022
Cylinder Assy, Front Stabilizer W/tube
[01.2016 - 03.2017] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60022 |
— | ||
| replacement | |||||
|
48870
|
48870
48007-60023 Cylinder Assy, Front Stabilizer W/tube[01.2016 - 03.2017] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60023 |
from US $1,090.58 |
||
|
48870
|
48870
48007-60023 Cylinder Assy, Front Stabilizer W/tube[04.2017 -] GDJ150..6FC VX PACKAGE; GDJ150..6FC VX-L PACKAGE; KDJ150;GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48007-60023 |
from US $1,090.58 |
||
|
48890
|
48890
48890-60070 Tube Assy, Front Stabilizer Control, No.1FRONT STABILIZER CONTROL, NO.1 [06.2015 -] GRJ150..6FC;GRJ150..6F..GEN STABILIZER-WITH(KDSS) |
48890-60070 |
US $384.38 |
||
|
91552K1235
|
91552K1235
91552-K1235 BOLT FLANGE |
91552-K1235 |
US $3.23 |
||
|
91641H0820
|
91641H0820
91641-H0820 Bolt |
91641-H0820 |
from US $0.80 |
||
|
9011908A33
|
9011908A33
90119-08A33 BOLT |
90119-08A33 |
from US $0.78 |
||
|
9011912386
|
9011912386
90119-12386 BOLT WWASHER |
90119-12386 |
US $3.76 |
||
|
9011914118
|
9011914118
90119-14118 BOLT W-WASHER |
90119-14118 |
from US $3.35 |
||
|
9011914124
|
9011914124
90119-14124 BOLT WWASHER |
90119-14124 |
US $4.56 |
||
|
9017814011
|
9017814011
90178-14011 Nut(For Suspension Lower Arm Shaft) |
90178-14011 |
from US $1.29 |
||
|
9041006002
|
9041006002
90410-06002 Seat, Union(For Power Steering Control Valve) |
90410-06002 |
US $3.94 |
||
|
9671124015
|
9671124015
96711-24015 Ring, O (For Front Power Take-Off Shaft) |
96711-24015 |
US $2.51 |
||
