Throttle Link & Valve Lever (Atm) ([11.1995 - ] (9511- )) Diagram Toyota LEXUS LX
- Year
- 1995 - 1998
- Sales region
- U.S.A.
- Frame
- FZJ80
- ENGINE
- 1FZFE
- TRANSMISSION
- ATM
- Model
- LX450
- From
- 11.1995
- To
- 01.1998
- Vehicle Model
- LX450
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35520
|
35520
35520-60140
Cable Assy, Throttle
[11.1995 - 01.1998] FZJ80 |
35520-60140 |
— | ||
|
35520B
|
35520B
90301-09012 Ring, O (For Automatic Transmission Case Plug)[11.1995 - 01.1998] FZJ80 |
90301-09012 |
US $3.94 |
||
|
35523A
|
35523A
35523-60070 Clamp, Throttle Cable, No.1[11.1995 - 01.1998] FZJ80 |
35523-60070 |
US $6.81 |
||
|
35524
|
35524
35524-60011 Clamp, Throttle Cable, No.2[11.1995 - 01.1998] FZJ80 |
35524-60011 |
US $10.48 |
||
| replacement | |||||
|
35524
|
35524
35524-60012 Clamp, Throttle Cable, No.2[11.1995 - 01.1998] FZJ80 |
35524-60012 |
US $10.34 |
||
|
91611B0816
|
91611B0816
91611-B0816 Bolt |
91611-B0816 |
from US $1.01 |
||
|
9046108681
|
9046108681
90461-08681
Clamp, Throttle Cable, No.4
|
90461-08681 |
— | ||
|
9165140610
|
9165140610
91651-40610 RIVET |
91651-40610 |
US $2.87 |
||
