Steering Column & Shaft ([10.1986 - ] (8610- )) Diagram Toyota LITE/ TOWNACE
- Year
- 1986 - 1990
- Sales region
- Japan
- Frame
- KM50
- grade
- DX
- body
- SJL
- ENGINE
- 4K
- TRANSMISSION
- MTM
- Model
- LITE/TOWNACE TRUCK
- From
- 10.1986
- To
- 08.1990
- Gear Shift Type
- 4H
- Vehicle Model
- LITE/TOWNACE TRUCK
- Deck(Type)
- 3SO
- Building Condition
- IV
- Deck(Material)
- TS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
45222E
|
45222E
45222-27030 Cover, Dust(For Steering Bevel Gear)[10.1986 - 06.1991] CM5#,6#,KM5#,YM55,6# |
45222-27030 |
US $4.54 |
||
|
45308D
|
45308D
90311-15001
Seal, Oil(For Steering Bevel Gear Housing)
[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 |
90311-15001 |
— | ||
| replacement | |||||
|
45308D
|
45308D
90311-15002 Seal, Oil(For Steering Bevel Gear Housing)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 |
90311-15002 |
from US $2.06 |
||
|
45308D
|
45308D
90311-15002 Seal, Oil(For Steering Bevel Gear Housing)[11.1987 - 05.1989] CM5#,KM5#,YM55 |
90311-15002 |
from US $2.06 |
||
|
45312A
|
45312A
45312-27090 Bracket, Steering Bevel Gear Housing[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
45312-27090 |
US $60.13 |
||
|
45380
|
45380
45380-28010 Gear Assy, Steering Bevel[10.1986 - 08.1988] CM5#,KM5#,YM55 |
45380-28010 |
US $476.11 |
||
| replacement | |||||
|
45380
|
45380
45380-28011 Gear Assy, Steering Bevel[10.1986 - 08.1988] CM5#,KM5#,YM55 |
45380-28011 |
US $476.11 |
||
|
45380
|
45380
45380-28011 Gear Assy, Steering Bevel[08.1988 -] CM50,51,55,KM5#,YM55 |
45380-28011 |
US $476.11 |
||
|
45380A
|
45380A
90209-18002 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝１．９０，マーク ２,T=1.90 |
90209-18002 |
US $3.32 |
||
|
45380A
|
45380A
90209-18003 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝１．９５，マーク ３,T=1.95 |
90209-18003 |
US $2.48 |
||
|
45380A
|
45380A
90209-18004 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝２．００，マーク ４,T=2.00 |
90209-18004 |
US $2.48 |
||
|
45380A
|
45380A
90209-18005 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝２．０５，マーク ５,T=2.05 |
90209-18005 |
US $2.48 |
||
|
45380A
|
45380A
90209-18006 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝２．１０，マーク ６,T=2.10 |
90209-18006 |
US $2.48 |
||
|
45380A
|
45380A
90209-18007 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝２．１５，マーク ７,T=2.15 |
90209-18007 |
US $2.48 |
||
|
45380A
|
45380A
90209-18008 Washer(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 厚さ＝２．２０，マーク ８,T=2.20 |
90209-18008 |
US $2.48 |
||
|
45383B
|
45383B
90501-18063 Spring, Compression(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 RR |
90501-18063 |
US $2.62 |
||
|
45383B
|
45383B
90501-20080 Spring, Compression(For Steering Bevel Gear)[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 FR |
90501-20080 |
US $1.40 |
||
|
45383C
|
45383C
90363-15010 Bearing, Radial Ball(For Steering Bevel Gear)[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
90363-15010 |
US $5.94 |
||
|
45384A
|
45384A
45384-27010 Cover, Steering Bevel Gear[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
45384-27010 |
US $12.96 |
||
|
45385A
|
45385A
45385-27010 Seat, Lock Bolt(For Steering Bevel Gear)[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
45385-27010 |
US $4.54 |
||
|
45385B
|
45385B
90113-08006 Bolt, Set(For Lock Bolt Seat)[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
90113-08006 |
US $1.05 |
||
|
45388
|
45388
45388-27010 Plate, Steering Bevel Gear[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
45388-27010 |
US $8.74 |
||
|
45389
|
45389
45389-27010 Holder, Steering Bevel Gear Spring[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 FR |
45389-27010 |
US $5.59 |
||
|
45389
|
45389
45389-27021 Holder, Steering Bevel Gear Spring[10.1986 - 11.1987] CM5#,6#,KM5#,YM55,60 RR |
45389-27021 |
US $5.82 |
||
|
45545B
|
45545B
45545-10010 Screw, Pinion Bearing Adjusting[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
45545-10010 |
US $13.80 |
||
|
45545C
|
45545C
90179-38001 Nut(For Pinion Bearing Adjusting Screw)[10.1986 - 10.1993] CM5#,6#,KM5#,YM55,6# |
90179-38001 |
US $8.21 |
||
|
9010110150
|
9010110150
90101-10150 Shaft, Brake Pedal |
90101-10150 |
US $2.48 |
||
|
9011906255
|
9011906255
90119-06255 New Genuine Part |
90119-06255 |
US $1.25 |
||
|
9011906447
|
9011906447
90119-06447 New Genuine Part |
90119-06447 |
US $2.91 |
||
|
9011910496
|
9011910496
90119-10496 New Genuine Part |
90119-10496 |
US $2.48 |
||
|
9017008021
|
9017008021
90170-08021 New Genuine Part |
90170-08021 |
US $1.05 |
||
|
9161161035
|
9161161035
91611-61035
BOLT
|
91611-61035 |
— | ||
| replacement | |||||
|
9161161035
|
9161161035
91612-61035 Bolt(For Hybrid Vehicle Transaxle & Engine Setting) |
91612-61035 |
from US $1.13 |
||
|
9165161030
|
9165161030
91651-61030 Bolt (For Transfer Case) |
91651-61030 |
from US $1.42 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.80 |
||
