Brake Tube & Clamp ([09.1973 - 11.1975] (7309-7511)) Diagram Toyota LITEACE
- Year
- 1971 - 1974
- Sales region
- General
- Frame
- KM10
- body
- TR
- ENGINE
- 3K
- Model
- LITEACE
- From
- 05.1971
- To
- 08.1974
- Vehicle Model
- LITEACE
- Driver's Position
- T3
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
47910
|
47910
47910-27010
Valve Assy, Load Sensing Proportioning
[09.1973 - 11.1975] KM10 |
47910-27010 |
— | ||
|
47920
|
47920
47920-27010
Spring Assy, Load Sensing
[09.1973 - 11.1975] KM10 |
47920-27010 |
— | ||
|
47920A
|
47920A
90387-08099 Collar(For Load Sensing Spring)[09.1973 - 11.1975] KM10 |
90387-08099 |
US $3.05 |
||
|
47920B
|
47920B
90467-31110 Clip(For Load Sensing Valve Boot)[09.1973 - 11.1975] KM10 |
90467-31110 |
US $2.15 |
||
|
47920C
|
47920C
90202-10103 Washer(For Load Sensing Spring)[09.1973 - 11.1975] KM10 |
90202-10103 |
US $2.15 |
||
|
47920K
|
47920K
04477-35010
Bush & Boot Kit, Load Sensing Spring
[09.1973 - 11.1975] KM10 |
04477-35010 |
— | ||
|
47931
|
47931
47931-27010
Bracket, Load Sensing Valve
[09.1973 - 11.1975] KM10 |
47931-27010 |
— | ||
|
47932
|
47932
47932-27010
Bracket, Load Sensing Valve, No.2
[09.1973 - 08.1974] KM10..TR |
47932-27010 |
— | ||
|
47933
|
47933
47933-27010
Bracket, Load Sensing Shackle, No.1
[09.1973 - 11.1975] KM10 |
47933-27010 |
— | ||
|
47935
|
47935
47935-35010 Shackle, Load Sensing Spring, No.1[09.1973 - 11.1975] KM10 |
47935-35010 |
US $28.39 |
||
|
47935A
|
47935A
90387-08099 Collar(For Load Sensing Spring)[09.1973 - 11.1975] KM10 |
90387-08099 |
US $3.05 |
||
|
47935B
|
47935B
90385-10064 Bush(For Load Sensing Spring Shackle)[09.1973 - 11.1975] KM10 |
90385-10064 |
from US $1.72 |
||
|
47935C
|
47935C
90948-02033 Retainer(For Load Sensing Spring Shackle)[09.1973 - 11.1975] KM10 |
90948-02033 |
US $7.71 |
||
|
47936
|
47936
47936-35010 Shackle, Load Sensing Spring, No.2[09.1973 - 11.1975] KM10 |
47936-35010 |
US $16.84 |
||
|
47937
|
47937
47937-26010
Plate, Load Sensing Valve Set
[09.1973 - 11.1975] KM10 |
47937-26010 |
— | ||
|
9113150840
|
9113150840
91131-50840 BOLT |
91131-50840 |
US $3.05 |
||
|
9161160816
|
9161160816
91611-60816
Screw Or Bolt(For Valve Rocker Shaft Lock)
|
91611-60816 |
— | ||
| replacement | |||||
|
9161160816
|
9161160816
91611-B0816 Bolt |
91611-B0816 |
from US $1.01 |
||
|
9165160816
|
9165160816
91651-60816 BOLT |
91651-60816 |
from US $1.01 |
||
| replacement | |||||
|
9165160816
|
9165160816
90080-11396 BOLT |
90080-11396 |
US $3.32 |
||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.84 |
||
|
9411041000
|
9411041000
94110-41000 Nut(For Steering Damper) |
94110-41000 |
US $2.87 |
||
|
9414140800
|
9414140800
94141-40800
New Genuine Part
|
94141-40800 |
— | ||
|
9451200800
|
9451200800
94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-00800 |
from US $0.68 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.80 |
||
|
9538102020
|
9538102020
95381-02020 PIN |
95381-02020 |
US $1.08 |
||
