Front Drum Brake Wheel Cylinder & Backing Plate ([10.1976 - 09.1979] (7610-7909)) Diagram Toyota LITEACE
- Year
- 1978 - 1979
- Sales region
- General
- Frame
- KM11
- body
- TR
- ENGINE
- 4KJ
- Model
- LITEACE
- From
- 02.1978
- To
- 09.1979
- Vehicle Model
- LITEACE
- Driver's Position
- T3
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04905
|
04905
04905-20040
Cup Kit, Front Wheel Cylinder
[10.1971 - 09.1979] KM1# |
04905-20040 |
— | ||
|
47041
|
47041
47041-27013 Plate Sub-Assy, Brake Backing, Front RhBRAKE BACKING, FRONT RH [10.1971 - 09.1979] KM1# |
47041-27013 |
US $57.80 |
||
|
47041C
|
47041C
90102-10016 Bolt(For Backing Plate To Steering Knuckle Arm Setting)[05.1971 - 09.1979] KM1# 10-1.25PX54-20 |
90102-10016 |
US $3.49 |
||
|
47041C
|
47041C
90102-10019 Bolt(For Backing Plate To Steering Knuckle Arm Setting)[05.1971 - 09.1979] KM1# 10-1.25PX51-22 |
90102-10019 |
US $3.20 |
||
|
47041D
|
47041D
90101-10148
Bolt(For Strut Bar Setting)
[05.1971 - 09.1979] KM1# 10-1.25PX27-16 |
90101-10148 |
— | ||
|
47041E
|
47041E
90171-10024 Nut(For Backing Plate To Steering Knuckle Arm Setting)[05.1971 - 09.1979] KM1# |
90171-10024 |
US $2.18 |
||
|
47041F
|
47041F
90170-10092 Nut(For Backing Plate To Steering Knuckle Setting)[05.1971 - 09.1979] KM1# |
90170-10092 |
US $2.33 |
||
|
47042
|
47042
47042-27013 Plate Sub-Assy, Brake Backing, Front LhBRAKE BACKING, FRONT LH [10.1971 - 09.1979] KM1# |
47042-27013 |
US $57.95 |
||
|
47410C
|
47410C
47446-10010 Spring(For Front Brake Shoe Hold Down)[10.1971 - 09.1979] KM1# |
47446-10010 |
US $3.58 |
||
|
47410D
|
47410D
90506-23388 Spring, Tension(For Front Brake Shoe Return)TENSION(FOR FRONT BRAKE SHOE RETURN) [10.1971 - 09.1979] KM1# |
90506-23388 |
US $3.64 |
||
|
47410E
|
47410E
90506-23388 Spring, Tension(For Front Brake Shoe Return)TENSION(FOR FRONT BRAKE SHOE RETURN) [10.1971 - 09.1979] KM1# |
90506-23388 |
US $3.64 |
||
|
47410L
|
47410L
04494-20091 Shoe Kit, Front BrakeFRONT BRAKE [03.1974 - 08.1978] KM1# |
04494-20091 |
US $148.51 |
||
| replacement | |||||
|
47410L
|
47410L
04494-20092 Shoe Kit, Front Brake[03.1974 - 08.1978] KM1# |
04494-20092 |
US $177.63 |
||
|
47410L
|
47410L
04494-27010 Shoe Kit, Front BrakeFRONT BRAKE [08.1978 - 09.1979] KM11 |
04494-27010 |
US $123.76 |
||
| replacement | |||||
|
47410L
|
47410L
04494-27011 Shoe Kit, Front Brake[08.1978 - 09.1979] KM11 |
04494-27011 |
US $171.81 |
||
|
47447
|
47447
47447-11010 Pin, Shoe Hold Down Spring(For Parking Brake)[10.1971 - 09.1979] KM1# |
47447-11010 |
from US $1.27 |
||
|
47491
|
47491
47491-20020 Plug, Hole(For Front Brake)[08.1972 - 09.1979] KM1# |
47491-20020 |
from US $1.79 |
||
|
47510
|
47510
47510-29155 Cylinder Assy, Front Wheel Brake, Rh(For Front Or Upper)FRONT WHEEL BRAKE, RH(FOR FRONT OR UPPER) [10.1976 - 09.1979] KM1# |
47510-29155 |
US $75.71 |
||
|
47510A
|
47510A
90410-03015
Seat, Union(For Clutch Master Cylinder)
[10.1976 - 09.1979] KM1# |
90410-03015 |
— | ||
|
47510K
|
47510K
04473-27010
Cylinder Kit, Front Wheel
[12.1976 - 09.1979] KM1# |
04473-27010 |
— | ||
|
47520
|
47520
47520-29075 Cylinder Assy, Front Wheel Brake, Rh(For Rear Or Lower)FRONT WHEEL BRAKE, RH(FOR REAR OR LOWER) [10.1976 - 09.1979] KM1# |
47520-29075 |
US $75.71 |
||
|
47530
|
47530
47530-29155 Cylinder Assy, Front Wheel Brake, Lh(For Front Or Upper)FRONT WHEEL BRAKE, LH(FOR FRONT OR UPPER) [10.1976 - 09.1979] KM1# |
47530-29155 |
US $75.71 |
||
|
47540
|
47540
47540-29075 Cylinder Assy, Front Wheel Brake, Lh(For Rear Or Lower)FRONT WHEEL BRAKE, LH(FOR REAR OR LOWER) [10.1976 - 09.1979] KM1# |
47540-29075 |
US $75.71 |
||
|
47547
|
47547
47547-12010 Plug, Bleeder(For Release Cylinder)[10.1976 - 09.1979] KM1# |
47547-12010 |
from US $2.32 |
||
|
47548
|
47548
31478-30010 Bleeder Plug Cap[10.1976 - 09.1979] KM1# |
31478-30010 |
from US $1.50 |
||
|
47551
|
47551
47551-20010 Nut, Front Wheel Cylinder Adjusting, Rh(For Front Brake)[10.1971 - 09.1979] KM1# LH.SCREW |
47551-20010 |
US $10.92 |
||
|
47552
|
47552
47552-20010 Nut, Front Wheel Cylinder Adjusting, Lh(For Front Brake)[10.1971 - 09.1979] KM1# RH.SCREW |
47552-20010 |
US $10.92 |
||
|
47553
|
47553
47553-20010 Bolt, Front Wheel Cylinder Adjusting, Rh(For Front Brake)[10.1971 - 09.1979] KM1# LH.SCREW |
47553-20010 |
US $8.30 |
||
|
47554
|
47554
47554-20010 Bolt, Front Wheel Cylinder Adjusting, Lh(For Front Brake)[10.1971 - 09.1979] KM1# RH.SCREW |
47554-20010 |
US $8.30 |
||
|
47555
|
47555
47555-20011 Spring, Adjuster Lock(For Front Brake)[07.1972 - 09.1979] KM1# |
47555-20011 |
US $3.35 |
||
|
47651
|
47651
47651-20101
Lining, Front Brake Shoe(For Front Or Upper)
[03.1974 - 09.1979] KM1# STD |
47651-20101 |
— | ||
|
47652
|
47652
47651-20101
Lining, Front Brake Shoe(For Front Or Upper)
[03.1974 - 09.1979] KM1# STD |
47651-20101 |
— | ||
|
9010108070
|
9010108070
90101-08070
Bolt, Hexagon
|
90101-08070 |
— | ||
| replacement | |||||
|
9010108070
|
9010108070
90119-08560 Bolt, Hexagon |
90119-08560 |
from US $1.13 |
||
|
9015950013
|
9015950013
90159-50013 New Genuine Part |
90159-50013 |
US $2.62 |
||
|
9161160814
|
9161160814
91611-60814 Bolt |
91611-60814 |
from US $0.76 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.80 |
||
|
9538102020
|
9538102020
95381-02020 PIN |
95381-02020 |
US $1.08 |
||
