Rear Spring & Shock Absorber ([01.1996 - ] (9601- )) Diagram Toyota MEGA CRUISER
- Year
- 1996 - 1999
- Sales region
- Japan
- Frame
- BXD20
- ENGINE
- 15BFT
- TRANSMISSION
- ATM
- From
- 01.1996
- To
- 06.1999
- Vehicle Model
- Mega Cruiser
- Fuel Induction
- TD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48107A
|
48107A
48107-65010 Arm Sub-Assy, Anchor, Rh[01.1996 -] BXD20 |
48107-65010 |
US $60.63 |
||
|
48108A
|
48108A
48108-65010 Arm Sub-Assy, Anchor, Lh[01.1996 -] BXD20 |
48108-65010 |
US $60.63 |
||
|
48161A
|
48161A
48161-65060 Spring, Rear Torsion Bar, Rh[01.1996 - 06.1999] BXD20 |
48161-65060 |
US $595.50 |
||
|
48162A
|
48162A
48162-65060 Spring, Rear Torsion Bar, Lh[01.1996 - 06.1999] BXD20 |
48162-65060 |
US $595.50 |
||
|
48173E
|
48173E
48173-36010 Seat, Anchor Arm Adjuster[01.1996 -] BXD20 |
48173-36010 |
US $8.44 |
||
|
48174C
|
48174C
48174-65010 Cover, Torsion Bar Dust[01.1996 -] BXD20 |
48174-65010 |
US $12.90 |
||
|
48530
|
48530
48530-65020
Absorber Assy, Shock, Rear Rh
[01.1996 - 06.1999] BXD20 |
48530-65020 |
— | ||
| replacement | |||||
|
48530
|
48530
48530-65040
Absorber Assy, Shock, Rear
[01.1996 - 06.1999] BXD20 |
48530-65040 |
— | ||
|
48532
|
48532
48532-65010 Pin, Rear Shock Absorber Pivot[01.1996 - 06.1999] BXD20 |
48532-65010 |
US $14.71 |
||
|
48533
|
48533
48533-65010 Pin, Rear Shock Absorber Lower Pivot, Rh[01.1996 -] BXD20 |
48533-65010 |
US $8.67 |
||
|
48533A
|
48533A
48533-65010 Pin, Rear Shock Absorber Lower Pivot, Rh[01.1996 -] BXD20 |
48533-65010 |
US $8.67 |
||
|
48540
|
48540
48530-65020
Absorber Assy, Shock, Rear Rh
[01.1996 - 06.1999] BXD20 |
48530-65020 |
— | ||
| replacement | |||||
|
48540
|
48540
48530-65040
Absorber Assy, Shock, Rear
[01.1996 - 06.1999] BXD20 |
48530-65040 |
— | ||
|
48635A
|
48635A
48635-65010 Bush, Upper Arm, Rear[01.1996 - 06.1999] BXD20 |
48635-65010 |
US $9.03 |
||
|
9010116032
|
9010116032
90101-16032 New Genuine Part |
90101-16032 |
US $3.20 |
||
|
9010118006
|
9010118006
90101-18006 New Genuine Part |
90101-18006 |
US $11.53 |
||
|
9017016022
|
9017016022
90170-16022 New Genuine Part |
90170-16022 |
US $2.87 |
||
|
9017018009
|
9017018009
90170-18009 New Genuine Part |
90170-18009 |
US $2.91 |
||
|
9017916026
|
9017916026
90179-16026 New Genuine Part |
90179-16026 |
US $2.15 |
||
|
9034506014
|
9034506014
90345-06014 Plug (For Ball Joint) |
90345-06014 |
US $1.97 |
||
|
9645100600
|
9645100600
96451-00600 Fitting, Grease Small(For Tail Gate Lock Link) |
96451-00600 |
from US $1.39 |
||
