Wiring & Clamp ([12.2008 - ] ｸﾗﾝﾌﾟ&ﾌﾞﾗｹｯﾄ (0812- )) Diagram Toyota PASSO
- Year
- 2008 - 2012
- Sales region
- Japan
- Frame
- M512E
- grade
- SC
- ENGINE
- 3SZVE
- Model
- PASSO SETTE
- From
- 12.2008
- To
- 03.2012
- Vehicle Model
- PASSO SETTE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
82111
|
82111
82111-B1750 Wire, Engine Room MainENGINE ROOM MAIN [12.2008 -] M512..SC,X; M502;M512..G,S 寒冷地仕様; M512..G Ｃ パッケージ; M502,512..G Ｃ パッケージ＆寒冷地仕様 |
82111-B1750 |
US $591.14 |
||
|
82111
|
82111
82111-B1760 Wire, Engine Room MainENGINE ROOM MAIN [12.2008 -] M502;M512..G,S 寒冷地仕様＆ヘッドランプ−２灯 ＨＩＤ; M502,512 ヘッドランプ−２灯 ＨＩＤ; M502,512..G Ｃ パッケージ＆寒冷地仕様＆ヘッドランプ−２灯 ＨＩＤ; M502,512..G Ｃ パッケージ＆ヘッドランプ−２灯 ＨＩＤ |
82111-B1760 |
US $591.14 |
||
|
82121
|
82121
82121-B1310 Wire, EngineENGINE [12.2008 - 03.2012] M502,512 |
82121-B1310 |
US $433.89 |
||
|
82123
|
82123
82123-B1090 Wire, Engine, No.3ENGINE, NO.3 [12.2008 -] M502,512 |
82123-B1090 |
US $75.71 |
||
|
82123
|
82123
82123-B1100 Wire, Engine, No.3ENGINE, NO.3 [12.2008 -] M502,512 寒冷地仕様 |
82123-B1100 |
US $75.71 |
||
|
57649B1030
|
57649B1030
57649-B1030 Gusset, Quarter Wheel House, No.1 Lh |
57649-B1030 |
US $4.08 |
||
|
57649B1060
|
57649B1060
57649-B1060 Gusset, Quarter Wheel House, No.1 Lh |
57649-B1060 |
US $5.68 |
||
|
57649B1070
|
57649B1070
57649-B1070 Gusset, Quarter Wheel House, No.1 Lh |
57649-B1070 |
US $4.08 |
||
|
82715B1010
|
82715B1010
82715-B1010 Bracket,wiring Harness Clamp |
82715-B1010 |
US $4.22 |
||
|
82715B1040
|
82715B1040
82715-B1040 Bracket,wiring Harness Clamp |
82715-B1040 |
US $8.15 |
||
|
82715B1080
|
82715B1080
82715-B1080 Bracket,wiring Harness Clamp |
82715-B1080 |
US $2.33 |
||
|
82715B1090
|
82715B1090
82715-B1090 Bracket,wiring Harness Clamp |
82715-B1090 |
US $2.62 |
||
|
82715B1110
|
82715B1110
82715-B1110 Bracket,wiring Harness Clamp |
82715-B1110 |
US $9.76 |
||
|
82715B1370
|
82715B1370
82715-B1370 Bracket Sub-Assy, Wire Harness |
82715-B1370 |
US $4.51 |
||
| replacement | |||||
|
82715B1370
|
82715B1370
82715-B1070 Bracket Sub-Assy, Wire Harness |
82715-B1070 |
US $2.48 |
||
|
87241B1010
|
87241B1010
87241-B1010 Controller, Water Valve |
87241-B1010 |
US $4.66 |
||
|
91621F0614
|
91621F0614
91621-F0614
BOLT WWASHER
|
91621-F0614 |
— | ||
| replacement | |||||
|
91621F0614
|
91621F0614
91621-J0612 BOLT W-WASHER |
91621-J0612 |
from US $0.65 |
||
|
91651G0616
|
91651G0616
91651-G0616 BOLT WWASHER |
91651-G0616 |
US $1.43 |
||
|
5764997401
|
5764997401
57649-97401 Gusset, Quarter Wheel House, No.1 Lh |
57649-97401 |
US $3.93 |
||
|
5764997404
|
5764997404
57649-97404 Gusset, Quarter Wheel House, No.1 Lh |
57649-97404 |
US $1.75 |
||
|
5764997405
|
5764997405
57649-97405 Gusset, Quarter Wheel House, No.1 Lh |
57649-97405 |
US $1.89 |
||
|
5764997406
|
5764997406
57649-97406 Gusset, Quarter Wheel House, No.1 Lh |
57649-97406 |
US $3.93 |
||
|
5764997407
|
5764997407
57649-97407 Gusset, Quarter Wheel House, No.1 Lh |
57649-97407 |
US $6.99 |
||
|
9161160610
|
9161160610
91611-60610
Bolt (For Transfer Oil Receiver No.1)
|
91611-60610 |
— | ||
| replacement | |||||
|
9161160610
|
9161160610
91611-B0610 Bolt (For Transfer Oil Receiver No.1) |
91611-B0610 |
from US $0.78 |
||
|
9162160612
|
9162160612
91621-60612
BOLTWWASHER
|
91621-60612 |
— | ||
| replacement | |||||
|
9162160612
|
9162160612
91621-J0612 BOLT W-WASHER |
91621-J0612 |
from US $0.65 |
||
|
9167180612
|
9167180612
91671-80612 Bolt |
91671-80612 |
from US $0.65 |
||
|
9167180816
|
9167180816
91671-80816 Bolt (For Transmission Control Cable Bracket) |
91671-80816 |
from US $0.76 |
||
