Valve Body & Oil Strainer (Atm) ([11.2006 - ] U660E (0611- )GSR50) Diagram Toyota PREVIA/ TARAGO
- Year
- 2006 - 2016
- Sales region
- General
- Frame
- GSR50
- grade
- GL
- ENGINE
- 2GRFE
- TRANSMISSION
- ATM
- DESTINATION
- GCC
- From
- 11.2006
- To
- 05.2016
- Gear Shift Type
- 6FC
- Seating Capacity
- 07S
- Driver's Position
- LHD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35196
|
35196
35196-33010 Clamp, Transaxle Apply Tube, No.2[11.2006 - 12.2008] GSR50 |
35196-33010 |
from US $3.06 |
||
|
35409
|
35409
35409-33010 Spring Sub-Assy, Manual Detent[11.2006 - 12.2008] GSR50 |
35409-33010 |
US $6.26 |
||
|
35599
|
35599
35599-33010 Cover, Manual Detent Spring[11.2006 - 12.2008] GSR50 |
35599-33010 |
US $2.77 |
||
|
35882A
|
35882A
35882-33040 Tube, Differential Gear Lube Apply[11.2006 - 12.2008] GSR50 |
35882-33040 |
US $5.97 |
||
|
9155180816
|
9155180816
91551-80816 Bolt(For Manual Transmission Oil Separator) |
91551-80816 |
from US $0.99 |
