Heating & Air Conditioning - Cooler Piping ([08.1988 - ] (8808- )) Diagram Toyota SUPRA
- Year
- 1989 - 1990
- Sales region
- Europe
- Frame
- MA70
- body
- LB
- ENGINE
- 7MGE
- TRANSMISSION
- MTM
- DESTINATION
- C
- Model
- SUPRA 70
- From
- 08.1989
- To
- 08.1990
- Gear Shift Type
- 5F
- Vehicle Model
- SUPRA
- Driver's Position
- LHD
- Fuel Induction
- TWC
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88453
|
88453
88453-12040 Fan, Cooling (For Condenser)[08.1988 - 05.1993] MA70..5F..TWC..(C,EUR) NO.1 |
88453-12040 |
US $22.36 |
||
|
88550
|
88550
88550-14030 Motor Assy, Blower (For Condenser)BLOWER (FOR CONDENSER) [08.1988 - 05.1993] MA70..5F..TWC..(C,EUR) NO.1 |
88550-14030 |
US $230.05 |
||
|
1670242010
|
1670242010
16702-42010 Shroud, Fan, No.2 |
16702-42010 |
US $44.63 |
||
|
8846714070
|
8846714070
88467-14070
Insulator (For Power Take-Off Cable Bracket)
|
88467-14070 |
— | ||
|
8846720040
|
8846720040
88467-20040
Insulator, Cooler Condenser Mounting
|
88467-20040 |
— | ||
|
8868814690
|
8868814690
88688-14690
Bracket, Cooler Diaphragm
|
88688-14690 |
— | ||
|
8868824140
|
8868824140
88688-24140
Bracket, Cooler Diaphragm
|
88688-24140 |
— | ||
|
9011906078
|
9011906078
90119-06078 New Genuine Part |
90119-06078 |
US $1.75 |
||
| replacement | |||||
|
9011906078
|
9011906078
90119-06330 Bolt |
90119-06330 |
US $1.43 |
||
|
9017906032
|
9017906032
90179-06032
Direct
|
90179-06032 |
— | ||
| replacement | |||||
|
9017906032
|
9017906032
90179-06274 Nut |
90179-06274 |
from US $0.70 |
||
|
9165140612
|
9165140612
91651-40612 BOLT |
91651-40612 |
from US $0.98 |
||
| replacement | |||||
|
9165140612
|
9165140612
90080-11225 New Genuine Part |
90080-11225 |
US $2.97 |
||
