Oil Cooler & Tube (Atm) ([10.2002 - ] U540E (0210- )AXP4#,SCP4#..ATM) Diagram Toyota VIOS
- Year
- 2005 - 2006
- Sales region
- General
- Frame
- AXP42
- grade
- GLS
- ENGINE
- 5AFE
- TRANSMISSION
- ATM
- DESTINATION
- CHI
- Model
- SOLUNA VIOS
- From
- 11.2005
- To
- 08.2006
- No.of Doors
- 4DS
- Vehicle Model
- SOLUNA VIOS
- Driver's Position
- LHD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
32904
|
32904
32904-52070 Tube Sub-Assy, Oil Cooler Inlet, No.1OIL COOLER INLET, NO.1 [11.2005 - 08.2006] AXP4#..ATM |
32904-52070 |
from US $21.84 |
||
|
32905
|
32905
32905-52050 Tube Sub-Assy, Oil Cooler Outlet, No.1OIL COOLER OUTLET, NO.1 [11.2005 - 08.2006] AXP4#..ATM |
32905-52050 |
US $20.68 |
||
|
32921D
|
32921D
32941-52010 Hose(For Oil Cooler Inlet)[11.2005 - 08.2006] AXP4#..ATM |
32941-52010 |
from US $19.66 |
||
|
32922A
|
32922A
32942-52010 Hose(For Oil Cooler Outlet)[11.2005 - 08.2006] AXP4#..ATM |
32942-52010 |
from US $23 |
||
|
32923
|
32923
32923-52020 Clamp, Automatic Transmission Oil Cooler TubeAUTOMATIC TRANSMISSION OIL COOLER TUBE [11.2005 - 08.2006] AXP4#..ATM |
32923-52020 |
US $5.24 |
||
|
9613551300
|
9613551300
96135-51300 Clamp, Hose |
96135-51300 |
from US $2.13 |
