Switch & Relay & Computer ([04.2013 - ] ENGINE & TRANSMISSION (1304- )NCP15#) Diagram Toyota YARIS/ ECHO/ VIOS/ LIMO
- Year
- 2014 - 2016
- Sales region
- General
- Frame
- NCP150
- ENGINE
- 1NZFE
- TRANSMISSION
- ATM
- DESTINATION
- VN
- CATEGORY
- B
- From
- 03.2014
- To
- 08.2016
- Gear Shift Type
- 4FC
- No.of Doors
- 4D
- Model Mark
- G
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
82715
|
82715
82715-5C120
Bracket,wiring Harness Clamp
[04.2013 - 09.2016] NCP15# |
82715-5C120 |
— | ||
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[04.2013 -] NCP15#,NSP150,151..B,C DENSO |
83530-28020 |
from US $24.41 |
||
| replacement | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [04.2013 -] NCP15#,NSP150,151..B,C DENSO |
83530-60020 |
from US $24.16 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [04.2013 -] NCP15#,NSP150,151..B,C YAZAKI |
83530-60020 |
from US $24.16 |
||
|
84540
|
84540
84540-46010 Switch Assy, Neutral Start[04.2013 - 09.2016] NCP15#..4FC |
84540-46010 |
from US $112.98 |
||
|
89465
|
89465
89465-52380 Sensor, OxygenOXYGEN NO.2 [04.2013 - 09.2016] NCP15#..GCC,GEN,IDN,MA,PH,TH,VN |
89465-52380 |
from US $142.68 |
||
|
89465A
|
89465A
89465-52700 Sensor, Oxygen No.2[04.2013 - 09.2016] NCP15#..GCC,GEN,IDN,MA,PH,TH,VN |
89465-52700 |
US $156.84 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[04.2013 -] NCP15#,NSP150,151..B,C |
89615-20090 |
from US $39.82 |
||
|
90105T0178
|
90105T0178
90105-T0178
New Genuine Part
|
90105-T0178 |
— | ||
|
90119T0221
|
90119T0221
90119-T0221 Bolt(For Clutch Release Cylinder Setting) |
90119-T0221 |
US $0.21 |
||
|
90119T0275
|
90119T0275
90119-T0275
New Genuine Part
|
90119-T0275 |
— | ||
|
90119T0304
|
90119T0304
90119-T0304
Bolt(For Clutch Release Cylinder Setting)
|
90119-T0304 |
— | ||
|
8271552A40
|
8271552A40
82715-52A40
Bracket,wiring Harness Clamp
|
82715-52A40 |
— | ||
|
9012608039
|
9012608039
90126-08039 Bolt, Stud(For Oil Pan) |
90126-08039 |
US $4.30 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.78 |
||
|
9043018008
|
9043018008
90430-18008 Gasket |
90430-18008 |
from US $0.90 |
||
| replacement | |||||
|
9043018008
|
9043018008
90430-T0021 Gasket(For Manual Transmission Filler Plug) |
90430-T0021 |
US $1.01 |
||
|
9155381014
|
9155381014
91553-81014 New Genuine Part |
91553-81014 |
US $1.31 |
||
|
9165140620
|
9165140620
91651-40620 BOLT |
91651-40620 |
from US $0.86 |
||
