Muffler Diagram Kawasaki JET SKI 750 STX JT750-C
- Engine Capacity
- 750
- Year
- 1998
- Commercial Name
- JT750-C
- Sales region
- Japan
- Colour
- Jet White (8C)
- Engine
- JT750BE 000001 -
- Stroke (2-stroke or 4-stroke)
- 2 stroke
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
92143A
|
92143A
92143-3759 COLLARカラ- |
92143-3759 |
from US $6.08 |
||
|
92143B
|
92143B
92143-3760 COLLARカラ- |
92143-3760 |
from US $4.77 |
||
|
92144
|
92144
92144-3751 SPRINGスプリング |
92144-3751 |
from US $10.01 |
||
|
92150B
|
92150B
92150-3819 BOLT,10X50ボルト，10X50 |
92150-3819 |
US $9.66 |
||
|
92150C
|
92150C
92150-3820 BOLT,10X145ボルト，10X145 |
92150-3820 |
from US $20.64 |
||
|
92150D
|
92150D
92150-3851 BOLT,SOCKET,8X30ボルト，ソケツト，8X30 |
92150-3851 |
from US $3.33 |
||
|
92150
|
92150
92150-3761 BOLT,6X80ボルト，6X80 |
92150-3761 |
from US $7.04 |
||
|
92150A
|
92150A
92150-3775 BOLTボルト，ソケツト，6X18 |
92150-3775 |
from US $3.17 |
||
|
92160
|
92160
92160-3774 DAMPER,RRダンパ，RR |
92160-3774 |
from US $15.50 |
||
|
92160A
|
92160A
92160-3879 DAMPERダンパ |
92160-3879 |
from US $2.93 |
||
|
92170
|
92170
92170-3718 Clampクランプ |
92170-3718 |
US $12.40 |
||
| replacement | |||||
|
92170
|
92170
92173-1401 CLAMPクランプ |
92173-1401 |
from US $9.35 |
||
|
92170A
|
92170A
92170-3748 CLAMPクランプ |
92170-3748 |
from US $12.67 |
||
|
92170B
|
92170B
92170-3754 CLAMPクランプ |
92170-3754 |
from US $11.57 |
||
| replacement | |||||
|
92170B
|
92170B
92171-3715 CLAMPクランプ |
92171-3715 |
from US $13.82 |
||
|
92180A
|
92180A
92180-3704 SHIMシム |
92180-3704 |
from US $10.80 |
||
|
92180
|
92180
92180-3703 SHIMシム |
92180-3703 |
US $5.86 |
||
|
92190
|
92190
92190-3953 TUBE, MANIFOLD-HULLチユ-ブ，マニホールド(ハル) |
92190-3953 |
from US $39.10 |
||
|
92191A
|
92191A
92191-3756 TUBE,CHAMBER-MUFFLERチユ-ブ，チヤンバ(マフラ) |
92191-3756 |
US $53.71 |
||
| replacement | |||||
|
92191A
|
92191A
92192-3810
TUBE,CHAMBER-MUFFLER
チユ-ブ，チヤンバ(マフラ) |
92192-3810 |
— | ||
|
92191B
|
92191B
92191-3766 TUBE,HEAD-EXHAUSTチユ-ブ，ヘツド(エキゾ-スト) |
92191-3766 |
from US $8.42 |
||
|
92191
|
92191
92191-3733 TUBEチユ-ブ |
92191-3733 |
from US $30.60 |
||
