Oil tank Diagram Kawasaki KSF80 KFX 80
- Model code
- KSF80-A1
- Engine Capacity
- 79
- Year
- 2003
- Sales region
- Canada
- Colour
- Lime Green (535)
- Power
- 4 hp
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
43049
|
43049
43049-S005 PACKING,OIL TANK CAP |
43049-S005 |
US $4 |
||
| replacement | |||||
|
43049
|
43049
43049-S019 Packing,Oil Tank Cap |
43049-S019 |
US $6.99 |
||
|
51049
|
51049
51049-S006 CAP-TANK |
51049-S006 |
US $9.49 |
||
|
52001
|
52001
52001-S002 TANK-OIL |
52001-S002 |
US $45.50 |
||
|
92153
|
92153
92153-S224 BOLT,OIL TANK |
92153-S224 |
US $1.78 |
||
|
92191
|
92191
92191-S050 TUBE,BRAKE BREATHER |
92191-S050 |
US $17.28 |
||
|
92200
|
92200
92200-S118 WASHER,OIL TANK |
92200-S118 |
US $1.13 |
||
