Brake caliper assembly Diagram Polaris CYCLONE
- Model code
- W877828
- Year
- 1987
- Sales region
- General
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
1930603
Kit,puck replacement
|
1930603 |
— | ||
| replacement | |||||
|
1
|
1
2200256 Kit,pucks,(replacement) |
2200256 |
US $149.66 |
||
|
2
|
2
1930604
Body, caliper
No Longer Available; |
1930604 |
— | ||
|
3
|
3
1930605
Grommet, pad
|
1930605 |
— | ||
|
4
|
4
1930606
O ring, caliper
|
1930606 |
— | ||
|
5
|
5
1930607
Guide,thrust
No Longer Available; |
1930607 |
— | ||
|
6
|
6
1930608
Arm, brake, asm.
|
1930608 |
— | ||
|
7
|
7
1930609
Bolt, adjust
|
1930609 |
— | ||
|
8
|
8
1930610
Ratchet, adjust
|
1930610 |
— | ||
|
9
|
9
1930611
Cover,caliper
|
1930611 |
— | ||
|
10
|
10
1930612
Spring, ratchet
|
1930612 |
— | ||
|
11
|
11
1930613
Gasket, caliper
|
1930613 |
— | ||
|
13
|
13
1930618
Stop, cable
|
1930618 |
— | ||
