Carburetor Diagram Yamaha CHAMP
- Model code
- 3GB4
- Engine Capacity
- 100
- Year
- 1990
- Sales region
- Europe (010)
- Colour
- Solid Fine Silver (SFS; 000A)
- Color Variant
- A
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Champ
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
38W-84710-00-00
Taillight Unit Assy
|
38W-84710-00-00 |
— | ||
|
2
|
2
3BW-84721-00-00
Lens, Taillight
|
3BW-84721-00-00 |
— | ||
|
3
|
3
3F9-84744-00-00 Bulb, Meter 12V 3.8W12V-5W |
3F9-84744-00-00 |
from US $2.09 |
||
| replacement | |||||
|
3
|
3
3F9-84744-00-XX Bulb, Meter 12V3.8W12V-5W |
3F9-84744-00-XX |
US $2.09 |
||
|
4
|
4
38W-84717-00-00 Taillight Unit Assy |
38W-84717-00-00 |
from US $42.88 |
||
| replacement | |||||
|
4
|
4
38W-84710-00-00
Taillight Unit Assy
|
38W-84710-00-00 |
— | ||
|
5
|
5
985-11040-20-00
Screw, Pan Head
|
985-11040-20-00 |
— | ||
| replacement | |||||
|
5
|
5
985-17040-20-00 Screw, Pan Head |
985-17040-20-00 |
from US $1.35 |
||
|
6
|
6
929-01046-00-00
Washer
|
929-01046-00-00 |
— | ||
| replacement | |||||
|
6
|
6
929-90046-00-00 Washer, Plate |
929-90046-00-00 |
from US $1.07 |
||
|
7
|
7
55X-84702-10-00
Bracket, Tail Light
|
55X-84702-10-00 |
— | ||
|
8
|
8
904-80133-98-00
Grommet
|
904-80133-98-00 |
— | ||
| replacement | |||||
|
8
|
8
90480-13014-00 Grommet |
90480-13014-00 |
from US $2.27 |
||
|
9
|
9
90387-067K6-00 Collar |
90387-067K6-00 |
from US $1.35 |
||
|
10
|
10
902-01060-59-00
Washer, Plate
|
902-01060-59-00 |
— | ||
| replacements | |||||
|
10
|
10
90201-06057-00 Washer, Plate |
90201-06057-00 |
from US $1.28 |
||
|
10
|
10
90201-06020-00 Washer, Plate |
90201-06020-00 |
from US $1.56 |
||
|
11
|
11
92506-06020-00 Screw |
92506-06020-00 |
from US $1.13 |
||
| replacement | |||||
|
11
|
11
98517-06020-00 Screw, Pan |
98517-06020-00 |
from US $1.13 |
||
|
12
|
12
929-06061-00-00
Washer, Spring
|
929-06061-00-00 |
— | ||
| replacement | |||||
|
12
|
12
92907-06100-00 Washer, Spring |
92907-06100-00 |
from US $0.93 |
||
