Front wheel Diagram Honda SK50
- Year
- 1993
- Model code
- SK50MP
- Sales region
- Spain
- Frame
- VTMAF27900E000002 - VTMAF27900E006201
- Engine Capacity
- 50
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
06430-GY1-922 Shoe set, brake |
06430-GY1-922 |
from US $24.58 |
||
|
2
|
2
42711-GAJ-902
Tire
|
42711-GAJ-902 |
— | ||
|
2
|
2
42711-GY1-922
Tire dunlop
|
42711-GY1-922 |
— | ||
|
2
|
2
42711-GAH-601
Tire(pirelli)
|
42711-GAH-601 |
— | ||
|
3
|
3
42712-GN2-612
Tube,tire (2.75/3
|
42712-GN2-612 |
— | ||
|
3
|
3
42712-GN2-622 Tube,tire |
42712-GN2-622 |
US $10.81 |
||
| replacement | |||||
|
3
|
3
42712-GF0-005 Tube,tire |
42712-GF0-005 |
US $10.81 |
||
|
3
|
3
42712-GAH-601
Tube 10c10
|
42712-GAH-601 |
— | ||
|
4
|
4
43151-GC4-000 Spring, brake shoe |
43151-GC4-000 |
from US $3.63 |
||
|
5
|
5
44301-GA7-000 Axle,fr.wheel |
44301-GA7-000 |
from US $9.77 |
||
| replacement | |||||
|
5
|
5
44301-051-010 Axle,front wheel |
44301-051-010 |
from US $9.77 |
||
|
6
|
6
44311-GW0-000 Collar,fr wheel s |
44311-GW0-000 |
US $7.84 |
||
|
7
|
7
44620-147-000 Collar, fr. distance |
44620-147-000 |
from US $6.22 |
||
|
8
|
8
44650-GY1-305ZB
Wheel set*nh322m*
|
44650-GY1-305ZB |
— | ||
|
9
|
9
44806-GW0-003 Gear,speedometer |
44806-GW0-003 |
US $11.25 |
||
|
10
|
10
45010-GW0-315ZH Panel sub*nh322m* |
45010-GW0-315ZH |
US $85.68 |
||
|
11
|
11
45134-165-890 Seal, brake cam |
45134-165-890 |
from US $2.43 |
||
|
12
|
12
45141-GC1-010 Cam, brake |
45141-GC1-010 |
from US $11.25 |
||
|
13
|
13
45145-GN2-000
Indicator, fr. brake
|
45145-GN2-000 |
— | ||
|
14
|
14
45410-GC1-000 Arm,fr.brake |
45410-GC1-000 |
US $14.06 |
||
|
15
|
15
45435-GC1-000
Return,spg,arm
|
45435-GC1-000 |
— | ||
|
16
|
16
90304-GE8-003 Nut, u, 10mm |
90304-GE8-003 |
from US $3.33 |
||
|
17
|
17
90754-147-003 Oil seal (19x30.5x7) |
90754-147-003 |
from US $5.48 |
||
|
18
|
18
91252-GF0-003 Oilseal 34x42x5 |
91252-GF0-003 |
from US $4 |
||
| replacement | |||||
|
18
|
18
91252-GF0-004 Oil seal (34x42x5) |
91252-GF0-004 |
from US $4.44 |
||
|
18
|
18
91252-GF0-004 Oil seal (34x42x5) |
91252-GF0-004 |
from US $4.44 |
||
|
19
|
19
92101-05025-0A Bolt, hex. (5x25) |
92101-05025-0A |
from US $0.47 |
||
|
20
|
20
93500-040-060-A ScrewPAN, 4X6 |
93500-040-060-A |
from US $0.37 |
||
|
21
|
21
94001-050-000-S NutHEX., 5MM |
94001-050-000-S |
from US $0.37 |
||
|
22
|
22
95015-31001 Joint aBRAKE ARM |
95015-31001 |
from US $0.74 |
||
|
23
|
23
9501541000 Nut a, brake rod adjusting |
9501541000 |
from US $0.81 |
||
|
24
|
24
96140-6200010 Bearing (6200u) |
96140-6200010 |
from US $5.48 |
||
