Fuel tank Diagram Kawasaki KX80 KX80 Big Wheel
- Year
- 1987
- Model code
- KX80-J2
- Sales region
- USA
- Engine Capacity
- 80
- Model
- KX80 Big Wheel
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
11009
|
11009
11009-1622
GASKET,FUEL TANK CAP
Gasket,fuel tank cap; |
11009-1622 |
— | ||
| replacement | |||||
|
11009
|
11009
11060-1340 GASKET,FUEL TANK CAPGasket,fuel tank cap; |
11060-1340 |
from US $4.59 |
||
|
51002
|
51002
51002-5351-6W TANK-COMP-FUEL,L.GREETank-comp-fuel,l.green; |
51002-5351-6W |
from US $457.67 |
||
|
51023
|
51023
51023-1115
TAP-ASSY-FUEL
Tap-assy,fuel; |
51023-1115 |
— | ||
|
51049
|
51049
51049-1089
Cap-tank
Cap-tank,fuel; |
51049-1089 |
— | ||
| replacement | |||||
|
51049
|
51049
51049-1108 CAP-TANK,FUELCap-tank,fuel; |
51049-1108 |
from US $20.28 |
||
|
92009
|
92009
92009-1386
SCREW PAN HEAD 3X8
Screw,3x8; |
92009-1386 |
— | ||
| replacement | |||||
|
92009
|
92009
220E0308 SCREW PAN HEAD 3X8Screw,3x8; |
220E0308 |
from US $1.11 |
||
|
92022
|
92022
92022-1690 WASHERWasher,6.5x24x2; |
92022-1690 |
from US $2.53 |
||
|
92027
|
92027
92027-1833 COLLAR,6.8X10X17Collar,6.8x10x17; |
92027-1833 |
from US $3.80 |
||
|
92055
|
92055
92055-1299 RING-ORing-o,fuel tap lever; |
92055-1299 |
from US $1.84 |
||
|
92055A
|
92055A
92055-1300 RING-ORing-o,fuel tap packing; |
92055-1300 |
from US $4.75 |
||
|
92059
|
92059
92059-1265
TUBE,5X9X350
Tube,5x9x350; |
92059-1265 |
— | ||
|
92075
|
92075
92075-1660 DAMPER |
92075-1660 |
from US $5.39 |
||
|
92150
|
92150
92150-1124 BOLTBolt,flanged,6x27; |
92150-1124 |
from US $2.69 |
||
|
187
|
187
187B0616
BOLT-UPSET-WSP
|
187B0616 |
— | ||
| replacement | |||||
|
187
|
187
187AA0616 BOLT-UPSET-WSP |
187AA0616 |
from US $1.70 |
||
