Front caliper Diagram Suzuki SMX50
- Year
- 2000
- Model code
- SMX50Y Y
- Engine Capacity
- 50
- Model
- SMX50
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
|
59300-00E10-000
Caliper assy, front
Caliper assy,front; |
59300-00E10-000 |
— | ||
|
1
|
1
59011-00E10-000
Piston set
|
59011-00E10-000 |
— | ||
|
2
|
2
59345-00E10-000
Spring, pad
|
59345-00E10-000 |
— | ||
|
3
|
3
59310-00E10-000
Piston
|
59310-00E10-000 |
— | ||
|
4
|
4
59350-00E10-000
Oil seal
Seal; |
59350-00E10-000 |
— | ||
|
5
|
5
08322-01083-000
WASHER
Washer; |
08322-01083-000 |
— | ||
| replacements | |||||
|
5
|
5
08322-0108B-000 WASHERWasher; |
08322-0108B-000 |
from US $0.80 |
||
|
5
|
5
08322-0108A-000 WASHERWasher; |
08322-0108A-000 |
from US $0.80 |
||
|
6
|
6
59346-00E10-000
Bolt
|
59346-00E10-000 |
— | ||
|
7
|
7
59121-00E10-000
Bleeder
Bleeder, set; |
59121-00E10-000 |
— | ||
|
8
|
8
D1507-08303-000
Bolt
|
D1507-08303-000 |
— | ||
|
9
|
9
59340-03E10-000
Pad set
|
59340-03E10-000 |
— | ||
|
10
|
10
59381-03E10-000
Shim. pad
Sim. pad; |
59381-03E10-000 |
— | ||
|
11
|
11
59103-03E00-000
O.ring
|
59103-03E00-000 |
— | ||
|
12
|
12
59246-03E00-E0N
Bracket
|
59246-03E00-E0N |
— | ||
|
13
|
13
D1507-08603-000
Bolt
|
D1507-08603-000 |
— | ||
