Oil tank Diagram Yamaha DT50 DT50
- Year
- 2000
- Colour
- Yamaha Black (YB; 0033)
- Model code
- 3UN7
- Sales region
- Portugal (010)
- Engine Capacity
- 50
- Model
- DT50LC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
5FC-21751-01-00 Tank, Oil |
5FC-21751-01-00 |
US $52.77 |
||
|
02
|
02
5R2-21771-00-00 Body, Cap |
5R2-21771-00-00 |
from US $19.03 |
||
|
03
|
03
17W-21796-00-00
Hinge
|
17W-21796-00-00 |
— | ||
|
04
|
04
98507-06016-00 Screw, Pan Head |
98507-06016-00 |
from US $1.42 |
||
|
05
|
05
92907-06600-00 Washer, Plate |
92907-06600-00 |
from US $1.04 |
||
|
06
|
06
91701-06035-00 Pin, Clevis (2F9) |
91701-06035-00 |
from US $1.98 |
||
|
07
|
07
90468-10050-00 Clip (156-83525-00) |
90468-10050-00 |
from US $1.84 |
||
|
08
|
08
90122-06020-00 Bolt, Wing |
90122-06020-00 |
from US $5.67 |
||
|
09
|
09
90201-06557-00 Washer, Plate |
90201-06557-00 |
from US $1.70 |
||
| replacement | |||||
|
09
|
09
90201-06020-00 Washer, Plate |
90201-06020-00 |
from US $1.56 |
||
|
10
|
10
4U5-2176E-00-00 Plate |
4U5-2176E-00-00 |
from US $3.40 |
||
|
11
|
11
3AC-23472-00-00 Protector |
3AC-23472-00-00 |
US $2.55 |
||
