Countershaft Diagram Honda ACCORD
- Year
- 1991
- Model code
- ACCORD
- Sales region
- General
- Engine
- F20A
- transmission
- 5MT
- Number of doors
- 4
- grade
- 2.0I
- area code
- KB
- left-hand drive
- +
- made in usa
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
23220-PX5-J40
Countershaft comp.
|
23220-PX5-J40 |
— | ||
|
2
|
2
23421-PX5-J40 GearCOUNTERSHAFT LOW |
23421-PX5-J40 |
US $130.56 |
||
|
3
|
3
23431-PX5-J40
Gear
|
23431-PX5-J40 |
— | ||
|
5
|
5
23461-PX5-C00
Gear
|
23461-PX5-C00 |
— | ||
|
6
|
6
23471-PX5-E00 GearCOUNTERSHAFT THIRD |
23471-PX5-E00 |
US $96.64 |
||
|
7
|
7
23481-PX5-E00 GearCOUNTERSHAFT FOURTH |
23481-PX5-E00 |
US $87.68 |
||
|
8
|
8
23521-PX5-305
Sleeve set
|
23521-PX5-305 |
— | ||
|
9
|
9
23917-PH8-000 Collar aDISTANCE, 36X44X29 (+0.05/+0.03) |
23917-PH8-000 |
US $14.21 |
||
|
9
|
9
23918-PH8-000
Collar b
|
23918-PH8-000 |
— | ||
|
10
|
10
23923-PG1-000
Washer c
|
23923-PG1-000 |
— | ||
|
10
|
10
23925-PG1-000
Washer e
|
23925-PG1-000 |
— | ||
|
10
|
10
23922-PG1-000
Washer b
|
23922-PG1-000 |
— | ||
|
10
|
10
23924-PG1-000
Washer d
|
23924-PG1-000 |
— | ||
|
10
|
10
23921-PG1-000 Washer a40X54X1.96 |
23921-PG1-000 |
US $10.06 |
||
|
11
|
11
23926-PG1-010
Washer
|
23926-PG1-010 |
— | ||
|
12
|
12
90202-PH8-000 NutHEX., 23MM |
90202-PH8-000 |
US $8.70 |
||
|
13
|
13
90602-PG1-770
Ring
|
90602-PG1-770 |
— | ||
|
14
|
14
91003-PG2-008 BearingSPECIAL BALL (NTN) |
91003-PG2-008 |
US $19.28 |
||
|
15
|
15
91102-PG2-008
Bearing
|
91102-PG2-008 |
— | ||
|
16
|
16
91105-PX5-008
Bearing
|
91105-PX5-008 |
— | ||
|
17
|
17
91107-PK5-008 BearingNEEDLE, 44X50X24 (TOYO) |
91107-PK5-008 |
US $7.98 |
||
|
18
|
18
91212-PX5-008
Damper
|
91212-PX5-008 |
— | ||
|
19
|
19
91211-PX5-008 DamperFRICTION (LOW) |
91211-PX5-008 |
US $14.72 |
