Countershaft Diagram Honda ACCORD
- Year
- 1993
- Model code
- ACCORD COUPE
- Sales region
- General
- Engine
- F20A
- transmission
- 5MT
- Number of doors
- 2
- grade
- 2.0I
- area code
- KG
- left-hand drive
- +
- air conditioner (manual)
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
23220-PX5-J41
Countershaft comp.
|
23220-PX5-J41 |
— | ||
|
2
|
2
23421-PX5-J41
Gear
|
23421-PX5-J41 |
— | ||
|
3
|
3
23431-PX5-J41
Gear
|
23431-PX5-J41 |
— | ||
|
4
|
4
23461-PX5-C01 GearCOUNTERSHAFT FIFTH |
23461-PX5-C01 |
US $58.62 |
||
|
5
|
5
23471-PX5-E01
Gear
|
23471-PX5-E01 |
— | ||
|
6
|
6
23481-PX5-E01
Gear
|
23481-PX5-E01 |
— | ||
|
7
|
7
23521-PX5-315
Sleeve set
00000000 - 8004163 |
23521-PX5-315 |
— | ||
|
7
|
7
23521-PX5-325
Sleeve set
8004164 - |
23521-PX5-325 |
— | ||
|
8
|
8
23918-P21-010 CollarDISTANCE, 36.5X42X29 (0.07-0.09) |
23918-P21-010 |
US $18.14 |
||
|
8
|
8
23917-P21-010
Collar
|
23917-P21-010 |
— | ||
|
9
|
9
23925-PG1-000
Washer e
|
23925-PG1-000 |
— | ||
|
9
|
9
23922-PG1-000
Washer b
|
23922-PG1-000 |
— | ||
|
9
|
9
23924-PG1-000
Washer d
|
23924-PG1-000 |
— | ||
|
9
|
9
23921-PG1-000 Washer a40X54X1.96 |
23921-PG1-000 |
US $10.06 |
||
|
9
|
9
23923-PG1-000
Washer c
|
23923-PG1-000 |
— | ||
|
10
|
10
23926-PG1-010
Washer
|
23926-PG1-010 |
— | ||
|
11
|
11
90202-PH8-000 NutHEX., 23MM |
90202-PH8-000 |
US $8.70 |
||
|
12
|
12
90602-PG1-770
Ring
|
90602-PG1-770 |
— | ||
|
13
|
13
91003-PG2-008 BearingSPECIAL BALL (NTN) |
91003-PG2-008 |
US $19.28 |
||
|
14
|
14
91102-PG2-008
Bearing
|
91102-PG2-008 |
— | ||
|
15
|
15
91105-PX5-008
Bearing
00000000 - 8004163 |
91105-PX5-008 |
— | ||
|
15
|
15
91105-P16-008
Bearing
8004164 - |
91105-P16-008 |
— | ||
|
16
|
16
91105-P21-003 BearingNEEDLE, 42X47X24 |
91105-P21-003 |
US $9.63 |
||
|
17
|
17
91211-PX5-008 DamperFRICTION (LOW) |
91211-PX5-008 |
US $14.72 |
||
|
18
|
18
91212-PX5-018 DamperFRICTION (SECOND) |
91212-PX5-018 |
US $10.78 |
