Rear beam/cross beam Diagram Honda ACCORD
- Year
- 2005
- Model code
- ACCORD
- Sales region
- General
- Engine
- K24A
- transmission
- 5AT
- Number of doors
- 4
- grade
- EX-L
- area code
- KD
- left-hand drive
- +
- leather seat
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
50200-SDC-A00
Sub frame comp.
|
50200-SDC-A00 |
— | ||
|
2
|
2
50220-SDA-A00
Stiffener
|
50220-SDA-A00 |
— | ||
|
4
|
4
50260-SDA-A01 RubberFR. SUB FRAME FR. MOUNTING |
50260-SDA-A01 |
US $34.82 |
||
|
5
|
5
50261-SDA-A02 Rubber, FR. SUB FRAME FR. STOPPER |
50261-SDA-A02 |
from US $10.82 |
||
|
6
|
6
50265-SDA-A00
Stay
|
50265-SDA-A00 |
— | ||
|
7
|
7
50266-SDA-A00
Stay
|
50266-SDA-A00 |
— | ||
|
8
|
8
50270-SDA-A01 RubberFR. SUB FRAME RR. MOUNTING |
50270-SDA-A01 |
US $34.82 |
||
|
9
|
9
50271-SDA-A01 Rubber, FR. SUB FRAME RR. STOPPER |
50271-SDA-A01 |
US $11.72 |
||
|
10
|
10
50275-SDA-A00
Stay
|
50275-SDA-A00 |
— | ||
|
11
|
11
50276-SDA-A00
Stay
|
50276-SDA-A00 |
— | ||
|
12
|
12
50280-SDA-A01 RubberR. FR. SUB FRAME MIDDLE MOUNTING |
50280-SDA-A01 |
from US $22.14 |
||
|
13
|
13
50285-SDA-A01 RubberL. FR. SUB FRAME MIDDLE MOUNTING |
50285-SDA-A01 |
from US $22.14 |
||
|
14
|
14
50300-SDD-Y00
Sub frame comp.
|
50300-SDD-Y00 |
— | ||
|
15
|
15
50354-S87-A00
Stay e
|
50354-S87-A00 |
— | ||
|
16
|
16
50355-S87-A00
Stay e
|
50355-S87-A00 |
— | ||
|
17
|
17
50356-S87-A00
Stay f
|
50356-S87-A00 |
— | ||
|
18
|
18
50357-S87-A00
Stay f
|
50357-S87-A00 |
— | ||
|
19
|
19
50360-SDB-A03 Rubber, RR. SUB FRAME FR. MOUNTING |
50360-SDB-A03 |
US $77.04 |
||
|
20
|
20
50361-SDB-A02 Rubber, RR. SUB FRAME STOPPER |
50361-SDB-A02 |
US $31.42 |
||
|
21
|
21
50370-SDB-A02 Rubber, RR. SUB FRAME RR. MOUNTING |
50370-SDB-A02 |
US $70.76 |
||
|
22
|
22
50371-SDB-A02 Rubber, RR. SUB FRAME STOPPER |
50371-SDB-A02 |
US $17.80 |
||
|
23
|
23
50410-SDA-A01 DamperFR. SUB FRAME FR. DYNAMIC |
50410-SDA-A01 |
US $38.53 |
||
|
24
|
24
50420-SDA-A01
Damper, FR. SUB FRAME RR. DYNAMIC
|
50420-SDA-A01 |
— | ||
|
25
|
25
50680-SDA-A00 BaseRR. ENGINE MOUNTING |
50680-SDA-A00 |
US $87.68 |
||
|
27
|
27
90164-SDA-A00 BoltFLANGE, 10X85 |
90164-SDA-A00 |
US $2.87 |
||
|
28
|
28
90166-S87-A00 BoltFLANGE, 8X16 |
90166-S87-A00 |
from US $1.12 |
||
|
29
|
29
90170-SDC-A00 BoltFLANGE, 10X34 |
90170-SDC-A00 |
US $2.45 |
||
|
30
|
30
90171-S3Y-000 BoltFLANGE, 10X35 |
90171-S3Y-000 |
US $2.31 |
||
|
31
|
31
90173-SDA-A00 BoltFLANGE, 10X55 |
90173-SDA-A00 |
US $1.47 |
||
|
32
|
32
90176-SDA-A00 BoltFLANGE, 14X135 |
90176-SDA-A00 |
from US $5.86 |
||
|
33
|
33
90177-SDA-A00 BoltFLANGE, 14X150 |
90177-SDA-A00 |
US $6.67 |
||
|
34
|
34
90179-SDA-A00 BoltFLANGE, 14X90 |
90179-SDA-A00 |
from US $3.78 |
||
|
35
|
35
90179-SDA-A00 BoltFLANGE, 14X90 |
90179-SDA-A00 |
from US $3.78 |
||
|
36
|
36
90186-SDA-A00 BoltFLANGE, 12X33 |
90186-SDA-A00 |
US $2.17 |
||
|
37
|
37
90189-SDA-A00 BoltFLANGE, 10X70 |
90189-SDA-A00 |
US $2.03 |
||
|
38
|
38
90396-S5A-000 BoltFLANGE, 12X75 |
90396-S5A-000 |
US $4.34 |
||
|
39
|
39
91613-SE0-003 GrommetSUB FRAME, 15MM |
91613-SE0-003 |
US $3.18 |
||
|
40
|
40
91613-S84-A00 GrommetRR. SUB FRAME |
91613-S84-A00 |
US $2.24 |
||
|
41
|
41
95701-080-160-8 BoltFLANGE, 8X16 |
95701-080-160-8 |
from US $0.59 |
||
|
42
|
42
95701-100-160-8 BoltFLANGE, 10X16 |
95701-100-160-8 |
from US $0.74 |
||
|
43
|
43
95701-120-250-8 BoltFLANGE, 12X25 |
95701-120-250-8 |
from US $1.04 |
