Front shock absorber Diagram Honda CITY
- Year
- 2002
- Model code
- CITY
- Sales region
- General
- Engine
- D13B
- transmission
- 5MT
- Number of doors
- 4
- grade
- LXI-S
- area code
- KY
- left-hand drive
- +
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
51401-SX8-T01
Spring
|
51401-SX8-T01 |
— | ||
|
2
|
2
51402-SX8-T01
Rubber
|
51402-SX8-T01 |
— | ||
|
3
|
3
51601-SX8-T04
Absorber assy
|
51601-SX8-T04 |
— | ||
|
4
|
4
51602-SX8-T04
Absorber assy
|
51602-SX8-T04 |
— | ||
|
5
|
5
51605-SX8-T04
Absorber unit
|
51605-SX8-T04 |
— | ||
|
6
|
6
51606-SX8-T04
Absorber unit
|
51606-SX8-T04 |
— | ||
|
7
|
7
51688-SX8-T01
Seat
|
51688-SX8-T01 |
— | ||
|
8
|
8
51689-SX8-T01
Washer
|
51689-SX8-T01 |
— | ||
|
9
|
9
51722-SX8-T01
Rubber
|
51722-SX8-T01 |
— | ||
|
10
|
10
51726-SF4-013 BearingSHOCK ABSORBER MOUNTING |
51726-SF4-013 |
US $14.72 |
||
|
11
|
11
51920-SX8-T01
Mount comp
|
51920-SX8-T01 |
— | ||
|
12
|
12
51924-SX8-T01
Washer
|
51924-SX8-T01 |
— | ||
|
13
|
13
90213-ST6-000 NutSELF-LOCK, 12MM |
90213-ST6-000 |
US $4.34 |
||
|
14
|
14
94050-10080 NutFLANGE, 10MM |
94050-10080 |
from US $0.74 |
