Rear brake drum (WAGON) Diagram Honda CIVIC
- Year
- 1983
- Model code
- CIVIC WAGON
- Sales region
- General
- Engine
- EN1
- transmission
- 5MT
- Number of doors
- 5
- grade
- DX
- area code
- KG
- rear wiper
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
42100-SA2-040
Beam comp
|
42100-SA2-040 |
— | ||
|
2
|
2
42324-671-010
Washer
0C202806 - |
42324-671-010 |
— | ||
|
3
|
3
42325-671-000
Holder
|
42325-671-000 |
— | ||
|
4
|
4
42326-SA0-000 CapHUB |
42326-SA0-000 |
US $9.24 |
||
|
5
|
5
42610-SA3-010
Drum
|
42610-SA3-010 |
— | ||
|
6
|
6
90113-SA0-013 BoltWHEEL (TOKAI TRW) 0S300001 - |
90113-SA0-013 |
US $4.62 |
||
|
6
|
6
90113-SA0-015 BoltWHEEL (NAGOYA RASHI) 0S300001 - |
90113-SA0-015 |
US $2.96 |
||
| replacement | |||||
|
6
|
6
90113-SM1-005 BoltWHEEL (ROCKNEL FASTENER) 0S300001 - |
90113-SM1-005 |
from US $3.70 |
||
|
7
|
7
90402-SA0-000
Nut
|
90402-SA0-000 |
— | ||
|
8
|
8
91052-671-004
Bearing assy
|
91052-671-004 |
— | ||
|
8
|
8
91052-671-008
Bearing assy
|
91052-671-008 |
— | ||
|
9
|
9
91053-671-004 Bearing assyRR. HUB (B) (KOYO SEIKO) |
91053-671-004 |
US $32 |
||
|
9
|
9
91053-671-008
Bearing assy
|
91053-671-008 |
— | ||
|
10
|
10
91252-692-005 SealRR. HUB (NOK) |
91252-692-005 |
US $9.80 |
||
|
10
|
10
91252-692-003
Seal
|
91252-692-003 |
— | ||
|
11
|
11
91301-567-003
O-ring
|
91301-567-003 |
— | ||
|
12
|
12
91352-SA2-000
Seal
|
91352-SA2-000 |
— | ||
|
13
|
13
94201-40250 PinSPLIT, 4.0X25 |
94201-40250 |
from US $0.44 |
||
