Rear brake caliper Diagram Honda CIVIC
- Year
- 1990
- Model code
- CIVIC
- Sales region
- General
- Engine
- D16Z
- transmission
- 5MT
- Number of doors
- 3
- grade
- 1.6I
- area code
- KG
- left-hand drive
- +
- catalyst
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
43022-SH3-G01 Pad setRR. |
43022-SH3-G01 |
US $83.20 |
||
|
2
|
2
43210-SH3-G04
Caliper assy
|
43210-SH3-G04 |
— | ||
|
3
|
3
43214-SD2-931 CoverPISTON DUST |
43214-SD2-931 |
US $5.33 |
||
|
4
|
4
43215-SH3-931 Piston assy. |
43215-SH3-931 |
from US $30.33 |
||
|
5
|
5
43218-SD2-931 Cup |
43218-SD2-931 |
from US $2.45 |
||
|
6
|
6
43223-SD2-932 BEARING A |
43223-SD2-932 |
from US $5.18 |
||
|
7
|
7
43224-SD2-931 Spring bADJUSTING |
43224-SD2-931 |
US $9.45 |
||
|
8
|
8
43227-SF1-003 SpringPAD |
43227-SF1-003 |
US $18.67 |
||
|
9
|
9
43228-SD2-933 Shaft a |
43228-SD2-933 |
from US $17.91 |
||
|
10
|
10
43229-SD2-931 Rod |
43229-SD2-931 |
from US $2.52 |
||
|
11
|
11
43230-SH3-G04
Caliper assy
|
43230-SH3-G04 |
— | ||
|
12
|
12
43232-SD2-931 O-ring |
43232-SD2-931 |
from US $1.54 |
||
|
13
|
13
43233-SD2-931 Piston compSLEEVE |
43233-SD2-931 |
US $14.21 |
||
|
14
|
14
43234-SD2-931 CoverDUST |
43234-SD2-931 |
US $4.61 |
||
| replacement | |||||
|
14
|
14
43234-S04-003 CoverDUST |
43234-S04-003 |
from US $2.74 |
||
|
15
|
15
43235-SD2-931 Pin a |
43235-SD2-931 |
US $9.61 |
||
|
16
|
16
43236-SD2-931 Spacer |
43236-SD2-931 |
US $7.12 |
||
| replacement | |||||
|
16
|
16
43236-S04-003 Spacer |
43236-S04-003 |
US $9.59 |
||
|
17
|
17
43238-SD2-931 RingRETAINING |
43238-SD2-931 |
from US $3.57 |
||
|
18
|
18
43241-SD2-931 GuideSPRING |
43241-SD2-931 |
from US $2.87 |
||
|
19
|
19
43242-SD2-933 CoverSHAFT |
43242-SD2-933 |
from US $3.08 |
||
|
20
|
20
43243-SD2-931 NutPARKING |
43243-SD2-931 |
from US $3.34 |
||
|
21
|
21
43244-SD2-931 Retainer |
43244-SD2-931 |
US $4.22 |
||
|
22
|
22
43245-SH3-931 LeverR. |
43245-SH3-931 |
US $7.56 |
||
|
23
|
23
43246-SD2-931
Spring
|
43246-SD2-931 |
— | ||
|
24
|
24
43247-SH3-931 ArmR. |
43247-SH3-931 |
US $12.04 |
||
|
25
|
25
43248-SD2-933 Shaft b |
43248-SD2-933 |
US $36.74 |
||
|
26
|
26
43249-SG0-003
Bolt
|
43249-SG0-003 |
— | ||
|
27
|
27
43262-SD2-931
Pin b
|
43262-SD2-931 |
— | ||
| replacement | |||||
|
27
|
27
43262-S84-A51 Pin b |
43262-S84-A51 |
from US $7.25 |
||
|
28
|
28
43265-SH3-931 LeverL. |
43265-SH3-931 |
US $7.56 |
||
|
29
|
29
43266-SD2-931
Spring
|
43266-SD2-931 |
— | ||
|
30
|
30
43267-SH3-931 ArmL. |
43267-SH3-931 |
US $12.04 |
||
|
31
|
31
43352-692-003 ScrewBLEEDER |
43352-692-003 |
US $5.32 |
||
|
32
|
32
43353-SA0-003
Cap
|
43353-SA0-003 |
— | ||
| replacement | |||||
|
32
|
32
43353-SD5-003 CapBLEEDER SCREW |
43353-SD5-003 |
from US $2.12 |
||
|
33
|
33
45209-166-006 SealPISTON |
45209-166-006 |
from US $4.07 |
||
|
34
|
34
45240-SC2-003 BoltFLANGE, 8X22 |
45240-SC2-003 |
from US $3.03 |
||
|
35
|
35
92201-10028-0H BoltHEX., 10X28 |
92201-10028-0H |
from US $0.74 |
||
|
36
|
36
94111-10800 WasherSPRING, 10MM |
94111-10800 |
from US $0.44 |
||
