Torque converter housing Diagram Honda CIVIC
- Year
- 1992
- Model code
- CIVIC
- Sales region
- General
- Engine
- D15B
- transmission
- 4AT
- Number of doors
- 4
- grade
- DX
- area code
- KL
- left-hand drive
- +
Difficulties in parts search?
Difficulties in parts search?
Description | OEM Part # | Price | |||
---|---|---|---|---|---|
1
|
1
21110-P24-A00 Case comp.TORQUE CONVERTER |
21110-P24-A00 |
US $496.64 |
||
2
|
2
21220-P24-J00
Plate comp
|
21220-P24-J00 |
— | ||
3
|
3
23225-PH0-000 PlateOIL GUIDE |
23225-PH0-000 |
US $3.57 |
||
4
|
4
25420-P24-J00
Strainer
|
25420-P24-J00 |
— | ||
5
|
5
28261-P24-J00
Stay
|
28261-P24-J00 |
— | ||
6
|
6
28300-P24-J02
Solenoid assy.
00000000 - 1097771 |
28300-P24-J02 |
— | ||
6
|
6
28300-P24-J03
Solenoid assy.
1097772 - |
28300-P24-J03 |
— | ||
6
|
6
28300-P24-J01
Solenoid assy.
|
28300-P24-J01 |
— | ||
7
|
7
28320-P24-J01 Filter assyLOCK UP SOLENOID (KEIHIN) |
28320-P24-J01 |
US $20.94 |
||
7
|
7
28320-P24-J02
Filter assy
|
28320-P24-J02 |
— | ||
8
|
8
41010-P24-305 Case comp.DIFFERENTIAL |
41010-P24-305 |
US $300.80 |
||
9
|
9
41233-P24-J00
Gear
|
41233-P24-J00 |
— | ||
10
|
10
41312-PA9-010
Gear
|
41312-PA9-010 |
— | ||
11
|
11
90003-PA9-003 BoltFLANGE, 10MM |
90003-PA9-003 |
US $2.24 |
||
12
|
12
90024-612-000 BoltSEALING, 8MM |
90024-612-000 |
from US $1.78 |
||
13
|
13
90418-689-000 Ring 5SNAP, 80X2.9 |
90418-689-000 |
US $6.44 |
||
13
|
13
90415-689-000 Ring 2SNAP, 80X2.6 |
90415-689-000 |
US $6.44 |
||
13
|
13
90417-689-000 Ring 4SNAP, 80X2.8 |
90417-689-000 |
US $6.44 |
||
13
|
13
90419-PH8-000 Ring 6SNAP, 80X3.0 |
90419-PH8-000 |
US $5.32 |
||
13
|
13
90414-689-000 Ring 1SNAP, 80X2.5 |
90414-689-000 |
US $6.44 |
||
13
|
13
90416-689-000 Ring 3SNAP, 80X2.7 |
90416-689-000 |
US $6.44 |
||
14
|
14
90471-580-000 Packing8MM |
90471-580-000 |
from US $1.48 |
||
15
|
15
90608-PA9-000 CirclipEXTERNAL, 90MM |
90608-PA9-000 |
US $6.16 |
||
16
|
16
90705-PA9-000 Dowel pin14X25 |
90705-PA9-000 |
US $2.80 |
||
17
|
17
91001-591-004
Bearing
|
91001-591-004 |
— | ||
replacement | |||||
17
|
17
91001-PX4-004 BearingBALL, 40X68X9 (KOYO) |
91001-PX4-004 |
US $14.50 |
||
18
|
18
91101-PL4-003 BearingNEEDLE, 36X62X18 (NTN) |
91101-PL4-003 |
US $17.28 |
||
19
|
19
91205-PL3-A02
Oil seal
|
91205-PL3-A02 |
— | ||
replacement | |||||
19
|
19
91205-PL3-A01 Oil seal35X56X8 (ARAI) |
91205-PL3-A01 |
from US $7.98 |
||
19
|
19
91205-PL3-A01 Oil seal35X56X8 (ARAI) |
91205-PL3-A01 |
from US $7.98 |
||
20
|
20
91207-639-015 Oil seal44X68X8 (NOK) |
91207-639-015 |
US $10.36 |
||
21
|
21
91209-612-000
Oil seal
|
91209-612-000 |
— | ||
replacement | |||||
21
|
21
91209-612-003 Oil seal12X22X7 (ARAI) |
91209-612-003 |
from US $4.74 |
||
22
|
22
94301-14200 Dowel pin14X20 |
94301-14200 |
from US $1.04 |
||
23
|
23
95701-060-200-8 BoltFLANGE, 6X20 |
95701-060-200-8 |
from US $0.48 |
||
24
|
24
96100-620-830-0 BearingRADIAL BALL, 6208 |
96100-620-830-0 |
US $17 |
||
25
|
25
96220-50100 Roller5X10 |
96220-50100 |
from US $0.22 |
