Servo body (S4XA) Diagram Honda CIVIC
- Year
- 1996
- Model code
- CIVIC
- Sales region
- General
- Engine
- B16A
- transmission
- 4AT
- Number of doors
- 3
- grade
- SIR
- abs
- +
- power steering
- +
- area code
- KU
- right-hand drive
- +
- srs driver & passenger
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
22741-PN1-000 PipeLOW CLUTCH |
22741-PN1-000 |
US $5.88 |
||
|
2
|
2
22743-PF0-000 PipeTHIRD CLUTCH |
22743-PF0-000 |
US $9.10 |
||
|
3
|
3
22749-PW4-000 Pipe35MM |
22749-PW4-000 |
US $1.82 |
||
|
4
|
4
24271-PX4-000
Shaft
|
24271-PX4-000 |
— | ||
|
5
|
5
24278-P56-000 BaseSERVO DETENT |
24278-P56-000 |
US $21.89 |
||
|
6
|
6
24530-PN1-000
Sleeve comp.
|
24530-PN1-000 |
— | ||
|
7
|
7
27405-P4X-000 Body sub assy.SERVO |
27405-P4X-000 |
US $133.12 |
||
|
8
|
8
27561-P56-000 PistonLOW ACCUMULATOR |
27561-P56-000 |
US $12.18 |
||
|
9
|
9
27562-P56-000
Spring
|
27562-P56-000 |
— | ||
|
10
|
10
27563-P56-000 CollarLOW ACCUMULATOR |
27563-P56-000 |
US $10.22 |
||
|
11
|
11
27572-P56-000 PistonSECOND ACCUMULATOR |
27572-P56-000 |
US $13.02 |
||
|
12
|
12
27574-PX4-800 PistonTHIRD ACCUMULATOR |
27574-PX4-800 |
US $10.22 |
||
|
13
|
13
27577-P56-000
Spring
|
27577-P56-000 |
— | ||
|
14
|
14
27578-P56-000 CoverTOP ACCUMULATOR |
27578-P56-000 |
US $23.81 |
||
|
15
|
15
27581-P56-000
Spring
|
27581-P56-000 |
— | ||
|
16
|
16
27583-P56-000
Spring
|
27583-P56-000 |
— | ||
|
17
|
17
90001-PL5-000 BoltFLANGE, 6X93 |
90001-PL5-000 |
US $3.22 |
||
|
18
|
18
90001-PP6-000 BoltFLANGE, 6X133 |
90001-PP6-000 |
US $2.94 |
||
|
19
|
19
90001-PX4-000
Bolt
|
90001-PX4-000 |
— | ||
|
20
|
20
90001-P24-J00
Bolt
|
90001-P24-J00 |
— | ||
|
21
|
21
90003-PL5-Z00
Bolt
|
90003-PL5-Z00 |
— | ||
|
22
|
22
90433-PX4-000
Washer
|
90433-PX4-000 |
— | ||
|
23
|
23
91302-PF0-003 O-ring26.9X2.4 (NOK) |
91302-PF0-003 |
from US $2.22 |
||
|
24
|
24
91321-PF4-004 O-ring18.3X2.4(NOK) |
91321-PF4-004 |
from US $1.85 |
||
|
25
|
25
91324-PF4-004 O-ring28.3X2.4 (NOK) |
91324-PF4-004 |
from US $1.78 |
||
|
26
|
26
91326-PL5-003 O-ring26X2.4(NOK) |
91326-PL5-003 |
from US $2.70 |
||
|
27
|
27
91331-PC9-003 O-ring |
91331-PC9-003 |
from US $0.77 |
||
|
28
|
28
91344-PC9-004 O-ring29X2.4 (NOK) |
91344-PC9-004 |
from US $2.44 |
||
|
29
|
29
91344-580-000 O-ring31X2.7 (ARAI) |
91344-580-000 |
US $2 |
||
|
30
|
30
94521-15000 CirclipINTERNAL, 15MM |
94521-15000 |
US $0.44 |
||
|
31
|
31
95701-060-750-8 BoltFLANGE, 6X75 |
95701-060-750-8 |
from US $0.90 |
