Instrument panel garnish (RH; PASSENGER SIDE) Diagram Honda CIVIC
- Year
- 2003
- Model code
- CIVIC COUPE
- Sales region
- General
- Engine
- D17A
- transmission
- 5MT
- Number of doors
- 2
- grade
- SE
- area code
- KE
- right-hand drive
- +
- air conditioner (manual)
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
39601-S5A-A01 Knob assy |
39601-S5A-A01 |
US $10.22 |
||
|
2
|
2
39602-S5A-A01
Socket assy
|
39602-S5A-A01 |
— | ||
|
3
|
3
39603-S5P-A01
Ring assy
|
39603-S5P-A01 |
— | ||
|
4
|
4
66405-S04-010
Stay
|
66405-S04-010 |
— | ||
|
5
|
5
66417-SB3-670 RubberGLOVE BOX STOPPER |
66417-SB3-670 |
US $2.66 |
||
|
6
|
6
66418-SB2-000
Stopper
|
66418-SB2-000 |
— | ||
|
7
|
7
66844-SA7-000 CapINSTRUMENT PANEL STAY |
66844-SA7-000 |
US $4.07 |
||
|
8
|
8
77250-S5A-013ZA Panel assy.CENTER *NH365L 1* |
77250-S5A-013ZA |
US $55.30 |
||
|
9
|
9
77251-S5A-A02ZA
Case assy.
|
77251-S5A-A02ZA |
— | ||
|
10
|
10
77252-S5A-A02ZA
Case assy.
|
77252-S5A-A02ZA |
— | ||
|
11
|
11
77255-S5A-G00 Bracket comp.CENTER PANEL |
77255-S5A-G00 |
US $16 |
||
|
12
|
12
77280-S5A-G00ZA PocketAUTO RADIO *NH1L* |
77280-S5A-G00ZA |
US $37.56 |
||
|
13
|
13
77313-S5A-000ZA Cover setINSTRUMENT CENTER LOWER *NH167L* |
77313-S5A-000ZA |
US $10.22 |
||
|
14
|
14
77314-S5A-000ZA Box setINSTRUMENT CENTER LOWER *NH167L* |
77314-S5A-000ZA |
US $6.86 |
||
|
15
|
15
77345-S5A-000ZA Cover assy.PASSENGER UNDER *NH167L* |
77345-S5A-000ZA |
US $48 |
||
|
16
|
16
77500-S5A-003ZA Box assyGLOVE *NH167L* |
77500-S5A-003ZA |
US $96 |
||
|
17
|
17
77541-S5A-000
Striker comp.
|
77541-S5A-000 |
— | ||
|
18
|
18
77631-S5A-A01 BushOUTLET |
77631-S5A-A01 |
US $1.33 |
||
|
19
|
19
77636-S5A-A01ZA
Case comp.
|
77636-S5A-A01ZA |
— | ||
|
20
|
20
77645-S5A-013ZA Outlet assyPASSENGER *NH167L* |
77645-S5A-013ZA |
US $46.08 |
||
|
21
|
21
77710-S5A-000ZA Ashtray comp.FR. *NH167L* |
77710-S5A-000ZA |
US $18.56 |
||
|
22
|
22
77730-S5A-003 Holder compFR. ASHTRAY |
77730-S5A-003 |
US $19.58 |
||
|
23
|
23
88315-SA5-000
Spring
|
88315-SA5-000 |
— | ||
|
24
|
24
88325-SA5-000
Spring
|
88325-SA5-000 |
— | ||
|
25
|
25
90133-SM4-003 Bolt-washer5X16 |
90133-SM4-003 |
US $1.82 |
||
|
26
|
26
90140-SH3-003 Bolt-washer5X18 |
90140-SH3-003 |
US $2.44 |
||
|
27
|
27
90302-SA4-003 NutSPRING, 4MM |
90302-SA4-003 |
from US $2.59 |
||
|
28
|
28
90666-S84-A01 ClipSNAP FITTING |
90666-S84-A01 |
from US $0.88 |
||
|
29
|
29
91640-SM4-003 GrommetSCREW, 4MM |
91640-SM4-003 |
US $1.95 |
||
|
30
|
30
93903-44480 ScrewTAPPING, 4X16 |
93903-44480 |
from US $0.37 |
||
|
31
|
31
93913-14280 ScrewTAPPING, 4X12 (PO) |
93913-14280 |
from US $0.37 |
||
|
32
|
32
93913-14420 ScrewTAPPING, 4X16(PO) |
93913-14420 |
from US $0.37 |
||
|
33
|
33
93913-24220 ScrewTAPPING, 4X12 |
93913-24220 |
from US $0.29 |
||
|
34
|
34
94305-40222 PinSPRING, 4X22 |
94305-40222 |
from US $0.89 |
||
|
35
|
35
77637-S9A-003 Seal aCLOSE |
77637-S9A-003 |
US $1.47 |
||
|
36
|
36
77638-S9A-003 Seal bOPEN |
77638-S9A-003 |
US $1.05 |
||
|
37
|
37
91641-SM4-003 GrommetSCREW, 4MM |
91641-SM4-003 |
US $1.95 |
