Front grille ('97-) Diagram Honda CIVIC
- Year
- 1997
- Model code
- CIVIC
- Sales region
- General
- Engine
- D14A
- transmission
- 5MT
- Number of doors
- 5
- grade
- 1.4I 7
- area code
- KG
- left-hand drive
- +
- air conditioner (dealer set)
- +
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
75101-ST3-E00
Grille
|
75101-ST3-E00 |
— | ||
|
2
|
2
75105-ST3-000
Bolt
|
75105-ST3-000 |
— | ||
|
3
|
3
75120-ST3-E00
Molding
|
75120-ST3-E00 |
— | ||
|
4
|
4
75133-ST3-000
Stopper
|
75133-ST3-000 |
— | ||
|
5
|
5
75135-ST3-E00
Stiffener
|
75135-ST3-E00 |
— | ||
|
6
|
6
75700-ST3-E00
Emblem
|
75700-ST3-E00 |
— | ||
|
7
|
7
90301-ST0-003 push nut, 3mm |
90301-ST0-003 |
from US $1.33 |
||
|
8
|
8
90157-SP0-901 ClipFR. GRILLE |
90157-SP0-901 |
US $2.17 |
||
|
9
|
9
75307-SN7-000 NutSIDE PROTECTOR |
75307-SN7-000 |
US $2.73 |
||
|
10
|
10
93903-423J0 ScrewTAPPING, 3X12 |
93903-423J0 |
US $0.67 |
||
|
11
|
11
90155-ST3-000
Washer
|
90155-ST3-000 |
— |
