Select lever (RH) Diagram Honda CIVIC
- Year
- 1998
- Model code
- CIVIC AERODECK
- Sales region
- General
- Engine
- D16B
- transmission
- 4AT
- Number of doors
- 5
- grade
- 1.6IES
- abs
- +
- area code
- KE
- right-hand drive
- +
- sunroof
- +
- air conditioner (manual)
- +
- colored outer handle
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35505-692-003 Bulb14V 1.4W |
35505-692-003 |
from US $2.07 |
||
|
2
|
2
35700-S04-003
Switch assy
|
35700-S04-003 |
— | ||
|
3
|
3
35701-ST3-G00
Bracket
|
35701-ST3-G00 |
— | ||
|
4
|
4
37700-S04-003
Lamp assy.
|
37700-S04-003 |
— | ||
|
5
|
5
54020-S04-982
Plate comp
|
54020-S04-982 |
— | ||
|
6
|
6
54100-S04-981 Lever compSELECT |
54100-S04-981 |
US $88.32 |
||
|
7
|
7
54110-S04-981
Spring comp
|
54110-S04-981 |
— | ||
|
8
|
8
54123-SL4-980 CollarSELECT LEVER |
54123-SL4-980 |
US $5.74 |
||
|
9
|
9
54131-SH3-981ZA KnobSELECT LEVER *NH1L* |
54131-SH3-981ZA |
US $44.84 |
||
|
10
|
10
54132-ST3-E81 KnobPUSH |
54132-ST3-E81 |
US $13.44 |
||
|
11
|
11
54133-SH9-980 SpringPUSH KNOB |
54133-SH9-980 |
US $2.65 |
||
|
12
|
12
54141-SV4-980 BushKNOB SETTING |
54141-SV4-980 |
from US $2.44 |
||
|
13
|
13
54200-S04-981 Bracket comp.SELECT LEVER |
54200-S04-981 |
US $28.29 |
||
|
14
|
14
54222-S04-981 CoverSELECT LEVER |
54222-S04-981 |
US $6.30 |
||
|
15
|
15
54315-SR3-983
Wire
|
54315-SR3-983 |
— | ||
|
16
|
16
54318-S04-981 SealBRACKET |
54318-S04-981 |
US $7 |
||
|
17
|
17
54319-SK3-E80
Seal
|
54319-SK3-E80 |
— | ||
|
18
|
18
54341-SA0-980
Boot
|
54341-SA0-980 |
— | ||
|
19
|
19
54351-SK3-E80
Bracket
|
54351-SK3-E80 |
— | ||
|
20
|
20
54361-SV4-980 PipeCONTROL WIRE ADJUSTING |
54361-SV4-980 |
US $8.82 |
||
|
21
|
21
54363-689-981 PinCONTROL WIRE ADJUSTER |
54363-689-981 |
US $3.57 |
||
|
22
|
22
54710-ST3-E82
Escutcheon comp.
|
54710-ST3-E82 |
— | ||
|
23
|
23
90130-SV4-980 ScrewTAPPING, 5X11 |
90130-SV4-980 |
US $2.24 |
||
|
24
|
24
90301-SD5-000 NutFLANGE, 6MM |
90301-SD5-000 |
from US $1.82 |
||
|
25
|
25
90308-SA0-981 NutSELF-LOCK, 6MM |
90308-SA0-981 |
from US $1.82 |
||
|
26
|
26
90438-671-000 WasherSPECIAL, 6MM |
90438-671-000 |
US $4.15 |
||
|
27
|
27
91555-SM4-003 ClipCOUPLER (RED) |
91555-SM4-003 |
from US $1.26 |
||
|
28
|
28
91580-SM4-003 ClipCOUPLER(ORANGE) |
91580-SM4-003 |
from US $1.68 |
||
|
29
|
29
91558-ST5-003 ClipHARNESS BAND(NATURAL) (135MM)(7MM HOLE) |
91558-ST5-003 |
US $1.68 |
||
|
30
|
30
92201-06060-0H BoltHEX., 6X60 |
92201-06060-0H |
US $0.59 |
||
|
31
|
31
93402-060-120-8 Bolt-washer6X12 |
93402-060-120-8 |
from US $0.52 |
||
|
32
|
32
93405-060-120-8 Bolt-washer6X12 |
93405-060-120-8 |
from US $0.59 |
||
|
33
|
33
93700-050-080-G ScrewOVAL, 5X8 |
93700-050-080-G |
from US $0.37 |
||
|
34
|
34
93893-050-100-8 Screw-washer5X10 |
93893-050-100-8 |
from US $0.52 |
||
|
35
|
35
94001-060-800-S NutHEX., 6MM |
94001-060-800-S |
from US $0.47 |
||
|
36
|
36
94050-06080 NutFLANGE, 6MM |
94050-06080 |
from US $0.50 |
||
|
37
|
37
94101-06800 WasherPLAIN, 6MM |
94101-06800 |
from US $0.36 |
