Carburetor insulator ('86,'87-1500) Diagram Honda CIVIC CRX
- Year
- 1986
- Model code
- CIVIC CRX
- Sales region
- General
- Engine
- EW2
- transmission
- 5MT
- Number of doors
- 3
- grade
- DX
- area code
- KY
- left-hand drive
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
16105-PC3-601
Gasket
|
16105-PC3-601 |
— | ||
|
2
|
2
16211-PE3-000
Insulator comp.
|
16211-PE3-000 |
— | ||
|
3
|
3
16232-PE3-731
Stay
|
16232-PE3-731 |
— | ||
|
4
|
4
16237-PE0-010
Clamp
|
16237-PE0-010 |
— | ||
|
5
|
5
17100-PE3-730
Manifold comp
|
17100-PE3-730 |
— | ||
|
6
|
6
17105-PE7-660
Gasket
|
17105-PE7-660 |
— | ||
|
7
|
7
17132-PE3-000
Stay
|
17132-PE3-000 |
— | ||
|
8
|
8
17406-PE4-730
Clamp
|
17406-PE4-730 |
— | ||
|
9
|
9
90023-PE0-000
Bolt
|
90023-PE0-000 |
— | ||
| replacement | |||||
|
9
|
9
95701-060-100-4 BoltFLANGE, 6X10 |
95701-060-100-4 |
US $0.52 |
||
|
10
|
10
90067-PE3-300
Bolt
|
90067-PE3-300 |
— | ||
|
11
|
11
94050-08080 NUT, FLANGE, 8MM |
94050-08080 |
from US $0.52 |
||
|
12
|
12
95700-060-120-8
Bolt
|
95700-060-120-8 |
— | ||
| replacement | |||||
|
12
|
12
95701-060-120-8 BoltFLANGE, 6X12 |
95701-060-120-8 |
from US $0.52 |
||
|
13
|
13
95700-080-200-8 BoltFLANGE, 8X20 |
95700-080-200-8 |
from US $0.59 |
||
| replacement | |||||
|
13
|
13
95701-080-200-8 BoltFLANGE, 8X20 |
95701-080-200-8 |
from US $0.58 |
||
|
14
|
14
95700-100-250-8 BoltFLANGE, 10X25 |
95700-100-250-8 |
from US $0.74 |
||
| replacement | |||||
|
14
|
14
95701-100-250-8 BoltFLANGE, 10X25 |
95701-100-250-8 |
from US $0.81 |
||
