Abs unit Diagram Honda CONCERTO
- Year
- 1993
- Model code
- CONCERTO
- Sales region
- General
- Engine
- D16A
- transmission
- 5MT
- Number of doors
- 5
- grade
- 1.6I-16
- abs
- +
- area code
- KE
- right-hand drive
- +
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
2
|
2
32165-SK3-G10
Bracket
|
32165-SK3-G10 |
— | ||
|
3
|
3
39790-SK3-G11
Abs control unit
|
39790-SK3-G11 |
— | ||
|
4
|
4
39792-SK3-E11
Bracket
|
39792-SK3-E11 |
— | ||
|
5
|
5
39795-SB2-003 Relay assyPOWER (4P) (MITSUBA) (RC-2201) |
39795-SB2-003 |
US $40.58 |
||
|
6
|
6
94050-06080 NutFLANGE, 6MM |
94050-06080 |
from US $0.52 |
||
|
7
|
7
93402-060-120-8 Bolt-washer6X12 |
93402-060-120-8 |
from US $0.52 |
