Rear door locks Diagram Honda INTEGRA
- Year
- 1998
- Model code
- INTEGRA
- Sales region
- General
- Engine
- B18B
- transmission
- 4AT
- Number of doors
- 4
- grade
- LS
- area code
- KD
- left-hand drive
- +
- sunroof
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35765-SH3-013
Sub switch comp.
|
35765-SH3-013 |
— | ||
|
2
|
2
72119-S04-003
Stopper a
|
72119-S04-003 |
— | ||
|
3
|
3
72120-ST7-023ZA
Handle assy
|
72120-ST7-023ZA |
— | ||
|
4
|
4
72122-SR2-003ZB CapINSIDE HANDLE CASE *NH167L* |
72122-SR2-003ZB |
US $3.26 |
||
|
5
|
5
72134-SM1-003 BushOUTSIDE HANDLE JOINT |
72134-SM1-003 |
from US $1.30 |
||
|
6
|
6
72135-SR3-003
Striker assy
|
72135-SR3-003 |
— | ||
|
7
|
7
72138-SL4-000
Cushion
|
72138-SL4-000 |
— | ||
|
8
|
8
72139-SR0-A01
Snap
|
72139-SR0-A01 |
— | ||
|
8
|
8
72616-SM4-003
Snap
|
72616-SM4-003 |
— | ||
|
9
|
9
72139-SR3-003 FastenerNATURAL |
72139-SR3-003 |
US $2.38 |
||
|
10
|
10
72139-ST8-A02
Tube
|
72139-ST8-A02 |
— | ||
|
12
|
12
72160-ST7-023ZA Handle assyL. INSIDE *NH167L* |
72160-ST7-023ZA |
US $27.39 |
||
|
13
|
13
72175-SH3-901 HolderDOOR LOCK ROD |
72175-SH3-901 |
US $4.32 |
||
|
14
|
14
72610-ST8-004
Lock assy
|
72610-ST8-004 |
— | ||
|
15
|
15
72615-SR4-J02
Actuator assy
|
72615-SR4-J02 |
— | ||
|
16
|
16
72616-SM4-003
Snap
|
72616-SM4-003 |
— | ||
|
17
|
17
72617-ST8-A02
Protector
|
72617-ST8-A02 |
— | ||
|
18
|
18
72626-ST8-023ZA
Case
|
72626-ST8-023ZA |
— | ||
|
19
|
19
72631-ST8-004
Rod
|
72631-ST8-004 |
— | ||
|
20
|
20
72632-ST8-004
Rod
|
72632-ST8-004 |
— | ||
|
21
|
21
72640-ST8-013ZY
Handle assy
|
72640-ST8-013ZY |
— | ||
|
21
|
21
72640-ST8-013ZR
Handle assy
|
72640-ST8-013ZR |
— | ||
|
21
|
21
72640-ST8-013ZD
Handle assy
|
72640-ST8-013ZD |
— | ||
|
21
|
21
72640-ST8-013ZP
Handle assy
|
72640-ST8-013ZP |
— | ||
|
22
|
22
72650-ST8-004
Lock assy
|
72650-ST8-004 |
— | ||
|
23
|
23
72655-SR4-J02
Actuator assy
|
72655-SR4-J02 |
— | ||
|
24
|
24
72657-ST8-A02
Protector
|
72657-ST8-A02 |
— | ||
|
25
|
25
72666-ST8-023ZA
Case
|
72666-ST8-023ZA |
— | ||
|
26
|
26
72671-ST8-004
Rod
|
72671-ST8-004 |
— | ||
|
27
|
27
72672-ST8-004
Rod
|
72672-ST8-004 |
— | ||
|
28
|
28
72680-ST8-013ZR
Handle assy
|
72680-ST8-013ZR |
— | ||
|
28
|
28
72680-ST8-013ZD
Handle assy
|
72680-ST8-013ZD |
— | ||
|
28
|
28
72680-ST8-013ZY
Handle assy
|
72680-ST8-013ZY |
— | ||
|
28
|
28
72680-ST8-013ZP
Handle assy
|
72680-ST8-013ZP |
— | ||
|
29
|
29
75411-634-000 Joint |
75411-634-000 |
US $2.52 |
||
|
30
|
30
90120-SV4-000 BoltLOCK STRIKER |
90120-SV4-000 |
US $1.63 |
||
|
31
|
31
90101-SR4-003 Screw3X10 |
90101-SR4-003 |
US $1.40 |
||
|
32
|
32
90120-SM4-000 ScrewTAPPING |
90120-SM4-000 |
US $1.55 |
||
|
33
|
33
90121-ST7-010 ScrewTAPPING |
90121-ST7-010 |
US $1.40 |
||
|
34
|
34
90662-SB2-003 GrommetSCREW, 5MM |
90662-SB2-003 |
US $1.85 |
||
|
35
|
35
91550-SH3-003ZG ClipRR. PANEL LINING *NH120L* |
91550-SH3-003ZG |
US $1.48 |
||
|
36
|
36
91580-SM4-003 ClipCOUPLER(ORANGE) |
91580-SM4-003 |
from US $1.68 |
||
|
37
|
37
93403-060-120-8 Bolt-washer6X12 |
93403-060-120-8 |
from US $0.45 |
||
|
38
|
38
93600-060-280-A ScrewFLAT, 6X28 |
93600-060-280-A |
from US $0.52 |
||
|
39
|
39
93901-22020 ScrewTAPPING, 3X6 |
93901-22020 |
from US $0.37 |
||
|
40
|
40
93903-22220 ScrewTAPPING, 3X10 |
93903-22220 |
from US $0.37 |
||
|
41
|
41
93903-45220 ScrewTAPPING, 5X12 |
93903-45220 |
US $0.37 |
||
|
42
|
42
94101-03800 WasherPLAIN, 3MM |
94101-03800 |
from US $0.37 |
