Steering wheel (SRS; 1) Diagram Honda LOGO
- Year
- 1999
- Model code
- LOGO
- Sales region
- General
- Engine
- D13B
- transmission
- 5MT
- Number of doors
- 3
- grade
- LOGO
- area code
- KG
- left-hand drive
- +
- srs driver
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
06770-S50-G70ZA
Module kit
|
06770-S50-G70ZA |
— | ||
|
3
|
3
78501-S04-N61ZF BodySTEERING WHEEL *NH283L* |
78501-S04-N61ZF |
US $337.92 |
||
|
4
|
4
78508-S04-N61
Tab
|
78508-S04-N61 |
— | ||
|
5
|
5
78509-S04-N61 CoverBOSS PLATE |
78509-S04-N61 |
US $2.66 |
||
|
6
|
6
78512-S04-N61ZE Cap cBODY COVER *NH283L* |
78512-S04-N61ZE |
US $2.73 |
||
|
7
|
7
78513-S04-N61ZE CapL. BODY COVER *NH283L* |
78513-S04-N61ZE |
US $2.73 |
||
|
8
|
8
78514-S04-N61ZE CapR. BODY COVER *NH283L* |
78514-S04-N61ZE |
US $2.73 |
||
|
10
|
10
78518-S04-N62ZE CoverBODY *NH283L* |
78518-S04-N62ZE |
US $14.46 |
||
|
11
|
11
78521-S04-N82ZE ButtonR. HORN *NH283L* |
78521-S04-N82ZE |
US $13.18 |
||
|
12
|
12
78522-S04-N82ZE
Button
|
78522-S04-N82ZE |
— | ||
|
13
|
13
90106-SA7-000 Screw-washer4X12 |
90106-SA7-000 |
US $3.60 |
||
| replacement | |||||
|
13
|
13
90133-SJ6-020 Screw-washer4X12 (PO) |
90133-SJ6-020 |
from US $2 |
||
|
14
|
14
90124-SR4-003 ScrewTAPPING, 4X10 |
90124-SR4-003 |
US $1.54 |
||
|
15
|
15
90134-S04-A81 BoltHEX., 6X12 |
90134-S04-A81 |
US $1.95 |
||
|
16
|
16
90161-SV4-003 BoltSTEERING HANDLE |
90161-SV4-003 |
US $3.03 |
||
|
19
|
19
93913-25520 ScrewTAPPING, 5X20 (PO) |
93913-25520 |
from US $0.44 |
||
