Abs unit (RH) Diagram Honda PRELUDE
- Year
- 1995
- Model code
- PRELUDE
- Sales region
- General
- Engine
- F22A
- transmission
- 4AT
- Number of doors
- 2
- grade
- S
- area code
- KQ
- right-hand drive
- +
- srs driver
- +
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
37740-P12-A01
Timer
|
37740-P12-A01 |
— | ||
|
2
|
2
37820-P12-A52
Control module
|
37820-P12-A52 |
— | ||
|
3
|
3
37821-P13-000
Cover comp.
|
37821-P13-000 |
— | ||
|
4
|
4
37822-P13-000
Sub stay comp.
|
37822-P13-000 |
— | ||
|
24
|
24
90361-SV4-003 NutPAINT CUTTING, 6MM |
90361-SV4-003 |
US $1.47 |
||
|
26
|
26
95701-060-120-8 BoltFLANGE, 6X12 |
95701-060-120-8 |
from US $0.52 |
||
|
27
|
27
95701-060-160-8 BoltFLANGE, 6X16 |
95701-060-160-8 |
from US $0.38 |
