Wire harness (RH) Diagram Honda PRELUDE
- Year
- 1994
- Model code
- PRELUDE
- Sales region
- General
- Engine
- F22A
- transmission
- 4AT
- Number of doors
- 2
- grade
- S
- area code
- KQ
- right-hand drive
- +
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
32100-SS0-Q01
Harness
|
32100-SS0-Q01 |
— | ||
|
2
|
2
32107-SS0-Q14
Harness
|
32107-SS0-Q14 |
— | ||
|
3
|
3
32108-SS0-Q01
Harness
|
32108-SS0-Q01 |
— | ||
|
5
|
5
32116-SS0-Q02
Harness
|
32116-SS0-Q02 |
— | ||
|
6
|
6
32117-SS0-Q52
Harness
|
32117-SS0-Q52 |
— | ||
|
7
|
7
32132-SM4-003 BandWIRE HARNESS OFFSET (20) (BLACK) (122.5MM) |
32132-SM4-003 |
US $2.73 |
||
|
8
|
8
32133-SM4-003 BandHARNESS OFFSET (30) (YELLOW) (122.5MM) |
32133-SM4-003 |
US $2.73 |
||
|
9
|
9
32134-SM4-003 BandHARNESS OFFSET (10) (BROWN) (122.5MM) |
32134-SM4-003 |
from US $3.03 |
||
|
10
|
10
32152-SD4-000
Separator
|
32152-SD4-000 |
— | ||
|
11
|
11
32155-SS0-010
Harness
|
32155-SS0-010 |
— | ||
|
12
|
12
32157-SS0-Q02
Harness
|
32157-SS0-Q02 |
— | ||
|
13
|
13
32160-SS0-000
Grommet a
|
32160-SS0-000 |
— | ||
|
14
|
14
32161-SS0-000
Grommet b
|
32161-SS0-000 |
— | ||
|
15
|
15
32202-SS0-000
Cord
|
32202-SS0-000 |
— | ||
|
16
|
16
32302-SS0-000
Bracket
|
32302-SS0-000 |
— | ||
|
17
|
17
32610-SS0-000
Cable
|
32610-SS0-000 |
— | ||
|
18
|
18
32751-SS0-Q13 HarnessFR. DRIVER DOOR WIRE |
32751-SS0-Q13 |
US $215.04 |
||
|
19
|
19
32752-SS0-E01
Harness
|
32752-SS0-E01 |
— | ||
|
20
|
20
38224-SB2-003 CaseFUSE(2P) |
38224-SB2-003 |
from US $6.30 |
||
|
22
|
22
90148-SE0-003 BoltEARTH, 6X16 (WASHER 12.5MM) (ZN) |
90148-SE0-003 |
from US $2.37 |
||
|
23
|
23
90149-SE0-003 BoltEARTH, 6X16 |
90149-SE0-003 |
from US $2.52 |
||
|
24
|
24
90153-SE0-003 BoltEARTH, 6X12 |
90153-SE0-003 |
from US $1.12 |
||
|
25
|
25
91506-SS0-003 ClipWIRE & WASHER TUBE |
91506-SS0-003 |
US $2.73 |
||
|
26
|
26
91507-SS0-003 ClipOFFSET, 30 (8MM) (BLACK) |
91507-SS0-003 |
US $2.59 |
||
|
28
|
28
91509-SA5-003 ClipOFFSET (45)(GRAY)(57MM) |
91509-SA5-003 |
US $2.38 |
||
|
29
|
29
91540-SV4-003 ClipHARNESS BAND (NATURAL) (145.2MM) |
91540-SV4-003 |
from US $2.81 |
||
|
30
|
30
91545-SV4-003 ClipHARNESS BAND (NATURAL) (145.2MM) (WITH SEAL) |
91545-SV4-003 |
US $3.11 |
||
|
32
|
32
91547-SH3-003 ClipBAND(NATURAL)(160MM) |
91547-SH3-003 |
US $2.52 |
||
|
34
|
34
91551-SF4-003 BandWIRE HARNESS(BROWN) (110MM) |
91551-SF4-003 |
from US $2.59 |
||
|
36
|
36
91552-SS0-003 ClipWIRE HARNESS (M5) (BROWN) (93.5MM) |
91552-SS0-003 |
US $1.68 |
||
|
37
|
37
91553-SS0-003
Clip
|
91553-SS0-003 |
— | ||
|
38
|
38
91555-SM4-003 ClipCOUPLER (RED) |
91555-SM4-003 |
from US $2.15 |
||
|
39
|
39
91556-SM4-003 ClipBAND (BLACK) (100MM) |
91556-SM4-003 |
US $2.31 |
||
|
40
|
40
91556-SP0-003 ClipCOUPLER(BROWN) |
91556-SP0-003 |
from US $1.26 |
||
|
41
|
41
91557-SS0-003 HolderCOUPLER (VIOLET) |
91557-SS0-003 |
US $1.61 |
||
|
43
|
43
91563-SF4-003 BandWIRE HARNESS (WHITE) (100.5MM) |
91563-SF4-003 |
US $2.03 |
||
|
46
|
46
91580-SM4-003 ClipCOUPLER(ORANGE) |
91580-SM4-003 |
from US $1.68 |
||
|
50
|
50
93405-060-120-8 Bolt-washer6X12 |
93405-060-120-8 |
from US $0.59 |
||
|
51
|
51
98200-31000 FuseBLADE (10A) |
98200-31000 |
from US $0.52 |
