Rear door panel & glass (PANEL,GLASS,HINGE ETC.) Diagram Mitsubishi DIAMANTE
- Year
- 1993 - 1994
- Sales region
- Japan
- Note
- 25V-SE(HARDTOP),4FA/T
- drive
- 2WD
- transmission
- 4FA/T
- grade
- 25V-SE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
68005B
|
68005B
MB364453 CUSHION, FR DOOR WINDOW GLASS |
MB364453 |
US $5.61 |
||
|
68005C
|
68005C
MB364459 CUSHION, RR DOOR |
MB364459 |
US $4.59 |
||
|
68015
|
68015
MB364455 HOOK, FR DOOR WINDOW GLASS STABILIZER |
MB364455 |
US $5.48 |
||
|
68015
|
68015
MB926277 HOOK, FR DOOR WINDOW GLASS STABILIZER |
MB926277 |
US $5.47 |
||
|
68019B
|
68019B
MB655940 BOLT, RR DOOR HINGEWasher assembled,8x25 |
MB655940 |
US $3.55 |
||
|
68019B
|
68019B
MU240121 BOLT, FR DOOR HINGEWasher assembled,8t,8x28 |
MU240121 |
US $2.60 |
||
|
68019C
|
68019C
MB142761 BOLT, FR SUSP STABILIZERWasher assembled,8x25 |
MB142761 |
from US $1.44 |
||
|
68019C
|
68019C
MB655944 BOLT, FR DOOR HINGEWasher assembled,10x25 |
MB655944 |
US $3.40 |
||
|
68019C
|
68019C
MU140017 BOLT, FR DOOR HINGEFlange,8x20 |
MU140017 |
from US $1.25 |
||
|
68020AL
|
68020AL
MB637349 PANEL ASSY, RR DOOR, LH |
MB637349 |
US $969.70 |
||
|
68020AL
|
68020AL
MB835715 PANEL ASSY, RR DOOR, LH |
MB835715 |
US $966.78 |
||
|
68020AR
|
68020AR
MB637350 PANEL ASSY, RR DOOR, RH |
MB637350 |
US $969.70 |
||
|
68020AR
|
68020AR
MB835716 PANEL ASSY, RR DOOR, RH |
MB835716 |
US $969.70 |
||
|
68025L
|
68025L
MB421931 PLATE, RR DOOR WINDOW GLASS ROLLER GUIDE, LH |
MB421931 |
US $24.42 |
||
|
68025R
|
68025R
MB421932 PLATE, RR DOOR WINDOW GLASS ROLLER GUIDE, RH |
MB421932 |
US $24.42 |
||
|
68026
|
68026
MB364451 PLATE, FR DOOR WINDOW GLASS |
MB364451 |
US $3.69 |
||
|
68030L
|
68030L
MB637351 PANEL, RR DOOR, OTR LH |
MB637351 |
US $297.02 |
||
|
68030L
|
68030L
MB637353 PANEL, RR DOOR, OTR LH |
MB637353 |
US $397.49 |
||
|
68030R
|
68030R
MB637352 PANEL, RR DOOR, OTR RH |
MB637352 |
US $297.02 |
||
|
68030R
|
68030R
MB637354 PANEL, RR DOOR, OTR RH |
MB637354 |
US $397.49 |
||
|
68040L
|
68040L
MB517417 HINGE, RR DOOR, LWR LH |
MB517417 |
US $44.40 |
||
|
68040L
|
68040L
MR134889 HINGE, RR DOOR, LWR LH |
MR134889 |
US $31.08 |
||
|
68040R
|
68040R
MB517418 HINGE, RR DOOR |
MB517418 |
US $44.40 |
||
|
68040R
|
68040R
MR134890 HINGE, RR DOOR, LWR RH |
MR134890 |
US $31.08 |
||
|
68044L
|
68044L
MB321764 STABILIZER, FR DOOR WINDOW GLASS |
MB321764 |
US $31.08 |
||
|
68044R
|
68044R
MB321763 STABILIZER, FR DOOR WINDOW GLASS |
MB321763 |
US $31.08 |
||
|
68045
|
68045
MB321762
STOPPER, FR DOOR WINDOW REGULATOR UP
|
MB321762 |
— | ||
| replacement | |||||
|
68045
|
68045
MR526916 STOPPER, FR DOOR WINDOW REGULATOR UP |
MR526916 |
US $9.85 |
||
|
68047L
|
68047L
MB655401 GUIDE, RR DOOR WINDOW GLASS, LH |
MB655401 |
US $28.86 |
||
|
68047R
|
68047R
MB655402 GUIDE, RR DOOR WINDOW GLASS, RH |
MB655402 |
US $28.86 |
||
|
68050L
|
68050L
MB626201 HINGE, RR DOOR, UPR LH |
MB626201 |
US $47.36 |
||
|
68050L
|
68050L
MR169835 HINGE, RR DOOR, UPR LH |
MR169835 |
US $34.78 |
||
|
68050R
|
68050R
MB626202 HINGE, RR DOOR, UPR RH |
MB626202 |
US $47.36 |
||
|
68050R
|
68050R
MR169836 HINGE, RR DOOR, UPR RH |
MR169836 |
US $34.78 |
||
|
68074
|
68074
MB626441 PLUG, RR DOORChild lock lever |
MB626441 |
US $2.66 |
||
|
68077B
|
68077B
MB655950 BOLT, FR DOOR WINDOW |
MB655950 |
US $4.59 |
||
|
68077C
|
68077C
MB364454 BOLT, FR DOOR WINDOWWeld,6x10 |
MB364454 |
from US $2.55 |
||
|
68077D
|
68077D
MS240397 BOLT, FR DOOR WINDOWWasher assembled,8x20 |
MS240397 |
US $5.06 |
||
|
68096B
|
68096B
MB364452 NUT, FR DOOR WINDOW6 |
MB364452 |
US $6.43 |
||
|
68096C
|
68096C
MS440502 NUT, FUEL TANKWasher assembled,6 |
MS440502 |
from US $1.74 |
||
|
68096D
|
68096D
MS440503 NUT, ENG FR MOUNTINGWasher assembled,8 |
MS440503 |
from US $0.84 |
||
|
68110L
|
68110L
MB763101 GLASS, RR DOOR WINDOW, LHAsahi |
MB763101 |
US $257.52 |
||
|
68110L
|
68110L
MB763102 GLASS, RR DOOR WINDOW, LHAsahi |
MB763102 |
US $297.02 |
||
|
68110R
|
68110R
MB763103 GLASS, RR DOOR WINDOW, RHAsahi |
MB763103 |
US $257.52 |
||
|
68110R
|
68110R
MB763104 GLASS, RR DOOR WINDOW, RHAsahi |
MB763104 |
US $297.02 |
||
|
68114
|
68114
MB655339 STRIKER, FR DOOR WINDOW GLASS, LH |
MB655339 |
US $4.59 |
||
|
68215
|
68215
MB574963 DAMPER, FR DOOR |
MB574963 |
from US $2.22 |
||
